Fanvil i16SV-02P Dubai


Fanvil i16SV-02P Dubai

The Fanvil i16SV-02P Dubai SIP Intercom stands at the forefront of outdoor communication solutions, embodying a fusion of state-of-the-art technology and robust design tailored to meet the demands of various environments.


Fanvil i16SV-02P SIP Intercom Dubai

The Fanvil i16SV-02P Dubai SIP Intercom stands at the forefront of outdoor communication solutions, embodying a fusion of state-of-the-art technology and robust design tailored to meet the demands of various environments. Engineered with a keen focus on reliability and functionality, this innovative device elevates communication standards with its exceptional features and unparalleled performance capabilities.

Designed to thrive in outdoor settings, the Fanvil i16SV-02P Dubai SIP Intercom boasts an impressive array of attributes aimed at ensuring seamless operation even in challenging conditions. Its adherence to IP65/IK10 protection standards underscores its resilience against dust, water, and physical impacts, guaranteeing uninterrupted functionality regardless of environmental factors. This commitment to durability positions the intercom as a dependable choice for diverse applications, ranging from industrial facilities to residential communities.

Beyond its robust construction, the Fanvil i16SV-02P Dubai SIP Intercom sets itself apart through its comprehensive suite of communication features, meticulously crafted to enhance user experience and efficiency. With crystal-clear audio transmission and high-definition video streaming capabilities, communication reaches new heights of clarity and reliability. Moreover, the intercom’s advanced broadcasting functionalities enable efficient dissemination of critical information across designated areas, empowering users to optimize communication workflows and ensure seamless coordination.

The Fanvil i16SV-02P Dubai SIP Intercom redefines the benchmarks of outdoor communication by seamlessly integrating cutting-edge technology, unmatched reliability, and uncompromising performance. As a versatile solution adaptable to various settings, it stands as a testament to innovation and excellence in the realm of modern communication infrastructure, catering to the evolving needs of users across diverse industries and applications.


  • Built-in HD camera with infrared night vision, adopt H.264 codec (only i16SV-02P)
  • IP65 waterproof and dustproof.
  • IK10 anti-collision with robust die-cast aluminum frame
  • Anti-tamper- alarming as long as the cover is apart from the housing, and reporting to the control center at the same time
  • HD voice speech quality with built-in 3W speaker and Acoustic Echo Canceller
  • Audio line out port, expandable external active speaker.
  • Built-in 2 short-in detect port and 2 short-out control port
  • Support built-in TF card slot for data storage or audio offline broadcasting.



  • 2 SIP lines
  • Speed dial
  • Linkage with IP camera to realize video intercom
  • Oral announcement of the IP address(in English)
  • MP3 broadcasting
  • Support programmable DSS key
  • Support mono active speaker
  • Talkback recording output
  • Switch signal input and output
  • Support TF card
  • PoE enabled

Device Functions

  • Auto-answering
  • Programmable DSS keys
  • Through button or web page volume adjustment
  • Network time synchronization
  • Time Plan (task management)
  • Incoming call multicast
  • Dynamic multicast function
  • Action URL / Active URI

Call Functions

  • Call out / answer / reject
  • Call waiting
  • Intercom, Multicast
  • Speed dial
  • Anonymous call (Hide caller ID)


  • Narrowband codec : G.711A/U, G.729A/B, iLBC, G.723, G.726-32K
  • Wideband codec : G.722, Opus
  • Full-duplex hands-free speakerphone with AEC
  • DTMF : In-band, Out-of-Band (RFC2833/ SIP INFO)

Video (Only i16SV-02P)

  • Sensor : 1/2.8” color CMOS
  • Pixels : 2 Mega
  • Video coding : H.264
  • Resolution : 720P/1080P
  • Minimum illumination : 0.1Lux, support for infrared illumination
  • Viewing angle :
    • Diagonal : 126°
    • Horizontal : 98°
    • Vertical : 65°


  • Physical : 10/100 Mbps Ethernet
  • IP mode : IPv4/IPv6/IPv4&IPv6
  • IP configuration : Static IP / DHCP / PPPoE
  • VPN : L2TP / OpenVPN
  • VLAN
  • LLDP
  • Qos


  • SIP2.0 over UDP/TCP/TLS
  • STUN
  • DHCP
  • IPv6
  • PPPoE
  • L2TP
  • OpenVPN
  • SNTP
  • TR-069

Physical Specifications

  • 2 DSS key (support LED)
  • RJ45 port x1 : connect the network
    • Power over Ethernet (IEEE 802.3af), class 3
  • Line out port x1 : connect the active speaker
    • Out : adjustable by volume, max up to1.2Vpp.
    • Port : terminal socket
  • Recording output port x1 : connect audio device
    • Out : mixed output of local microphone voice and call voice recording
    • Impedance : 15 Ohm
    • Port : terminal socket
  • Short circuit input and output port x2 (built-in relay)
    • Relay : MAX DC30V / 2A, AC125V / 0.5A
    • Active switching output : 12V/500mA DC(only 1 relay support)
    • Port : terminal socket
  • Tamper alarm switchx1
  • TF card slot x1 : connect TF card
  • DC port x1 : DC power input
    • DC power input : DC12V~24V/1A
    • Port : 2 Pin terminal socket
  • Protection level : IP65 and IK10
  • Housing material : aluminum alloy shell
  • Installation : wall-mounted
  • Working temperature : -30℃ ~ 60℃
  • Storage temperature : – 40℃ ~ 70℃
  • Working humidity : 10~95%
  • Net weight/box : 9.5 kg
  • Gross weight/box : 10.05 kg
  • Device dimensions : 195x120x40 mm
  • Gift box dimensions : 260x165x62 mm
  • Outer CTN dimensions : 348x328x280 mm (10 PCS)
