The Fanvil Y501 Dubai SIP healthcare intercoms represent a pinnacle in purpose-built solutions, meticulously designed to cater to the intricate needs of home-based care, nursing homes, and various indoor applications.


Fanvil Y501 SIP Intercoms Dubai

The Fanvil Y501 Dubai SIP healthcare intercoms represent a pinnacle in purpose-built solutions, meticulously designed to cater to the intricate needs of home-based care, nursing homes, and various indoor applications. Their standout features go beyond mere communication, encompassing a spectrum of functionalities aimed at enhancing emergency responsiveness, fortifying security measures, facilitating efficient broadcasting, and much more.

Crafted with cutting-edge technology, these intercoms are equipped with a plethora of advanced features. Among them are their high-definition audio capabilities, which ensure crystal-clear communication even in the most demanding environments. Supporting up to 2 SIP accounts, they provide users with flexibility and scalability in their communication setups. The detachable DSS keys further enhance adaptability, allowing users to customize and optimize their usage according to specific requirements.With IP54 waterproof and dustproof ratings, the Y501 series guarantees durability and reliability, making them resilient even in challenging conditions. Whether it’s in the midst of a bustling healthcare facility or a serene home environment, these intercoms remain steadfast in their performance.

Notably, the Y501 series introduces advanced connectivity options, including built-in 2.4G & 5G Wi-Fi in select variants (Y501W/Y501W-E). This feature opens doors to seamless integration within modern healthcare environments, ensuring smooth and uninterrupted communication pathways.Installation flexibility is another hallmark of the Y501 series. With versatile mounting options such as standard 86 box embedded and wall mountable configurations, these intercoms can be seamlessly integrated into any healthcare infrastructure, adapting effortlessly to diverse communication needs.

The Fanvil Y501 series redefines healthcare communication, setting new standards for efficiency and reliability. By providing timely and effective communication tools, they contribute significantly to enhanced patient care and operational efficiency in healthcare settings. Experience the epitome of healthcare communication with the Fanvil Y501 Dubai , where innovation meets practicality to deliver unparalleled performance.


  • Support specific 433MHz wireless button
  • Features 2 SIP accounts and 3 antibacterial material detachable function buttons
  • Support HD audio with codec G.722 and Opus
  • Built-in 2.4G&5G Wi-Fi(Y501W/Y501W-E)
  • Built-in 1 short circuit input/output interface
  • IP54 waterproof and dustproof
  • Support PoE power supply
  • Support wall mountable installation (Y501/Y501W) and 86 box embedded installation(Y501-E/Y501W-E)



  • 2 SIP Lines
  • Auto answer
  • HD Voice
  • PoE Enabled
  • Built-in 2.4GHz & 5G Wi-Fi(Y501W/Y501W-E)
  • Intercom function
  • External Power Supply (Optional)

Intercom Function

  • Support customized DSS keys
  • Support wireless button (Optional)
  • Network Time Synchronization
  • Built-in Wi-Fi
    • 2.4G, 802.11 b/g/n
    • 5G, 802.11 a/n
  • Action URL / Active URL


  • Narrowband Codec : G.711a/u, G.729AB, G.723.1, G.726, iLBC
  • Wideband Codec : G.722, Opus
  • Duplex intercom with Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer up to 300ms
  • DTMF : In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO


  • Physical : 10/100 Mbps Ethernet
  • WIFI : 2.4G & 5G (Y501W/Y501W-E)
  • IP Mode : IPv4/IPv6/IPv4&IPv6
  • IP Configuration : Static / DHCP / PPPoE
  • Wi-Fi Encryption : WPA /WPA2-PSK /802.X EAP
  • VPN : L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS


  • SIP2.0 over UDP/TCP/TLS
  • STUN
  • DHCP
  • IPv6
  • LLDP
  • PPPoE
  • L2TP
  • OpenVPN
  • SNTP
  • TR-069

Physical Specifications

  • Y501 Series : 3 DSS buttons (Speed dial, Emergency, Cancel)
  • Up to 10 wireless buttons supported
  • Status indicator light : Red(registration failed、network anomaly)、Green(registration successful、call)
  • 1 RJ45 port
  • 1 short circuit input interface
  • 1 relay : NC/NO Contacts, Max DC30V/1A, AC125V/0.5A
  • Power : DC12V/1A or POE
  • Power Consumption (Adapter):
    • 0.94W~1.98W(Y501/Y501-E)
    • 1.42W~2.35W(Y501W/Y501W-E)
  • Power Consumption (PoE):
    • 1.48W~2.37W(Y501/Y501-E)
    • 1.99W~3.05W(Y501W/Y501W-E)
  • Housing material : ABS
  • 433 wireless button specification:
    • communication mode:FSK
    • working frequency:433MHZ
    • communication protocol:Ebelong1.1
  • Installation : Indoor installation
    • Standard 86 Box Embedded
    • Wall Mountable
  • Color : White
  • working temperature : -10 ~50 °C
  • Storage temperature : -20 ~ 50 °C
  • Relative humidity : 10% – 90%
  • N.W/CNT : 3.7kg
  • G.W/CNT : 3.98kg
  • Equipment Dimension :
    • 87.56 x 87.56 x 30mm (Wall Mountable)
    • 87.56 x 87.56 x 21.5mm (86 Box Embedded)
  • Packing Dimension : 95x106x40mm
  • Outer CTN Dimension : 224x220x210mm (20 pcs)
