The Fanvil Y501-Y Dubai SIP healthcare intercoms stand as a pinnacle of technological advancement, meticulously designed to cater to a myriad of healthcare environments.


Fanvil Y501-Y SIP Intercom Dubai

The Fanvil Y501-Y Dubai SIP healthcare intercoms stand as a pinnacle of technological advancement, meticulously designed to cater to a myriad of healthcare environments. Whether deployed in home-based care setups, nursing homes, or other indoor facilities, these intercom systems redefine communication and security standards with their cutting-edge features and uncompromising reliability.Tailored to meet the unique demands of healthcare settings, the Fanvil Y501-Y Dubai SIP intercoms excel in facilitating critical functions such as emergency communication, security surveillance, and seamless broadcasting capabilities. By seamlessly integrating into existing infrastructures, they elevate the quality of care and safety within these environments, ensuring that patients and caregivers alike are supported with dependable communication tools.

At the heart of the Fanvil Y501-Y Dubai lies a host of features designed to optimize user experience and operational efficiency. From its impeccable high-definition audio quality to its ability to accommodate up to 2 SIP accounts for seamless connectivity, every aspect of its design is crafted with precision and effectiveness in mind. The inclusion of detachable DSS keys further enhances its functionality, allowing for customizable operations tailored to specific needs.Moreover, the Fanvil Y501-Y Dubai is engineered to endure the rigors of diverse environments, boasting an IP54 waterproof and dustproof rating that ensures durability and longevity even in demanding conditions. This robust construction guarantees uninterrupted performance, instilling confidence in users that communication channels remain steadfast regardless of external factors.

The Y501-Y series also introduces the convenience of built-in 2.4G & 5G Wi-Fi capabilities, offering flexible connectivity options that adapt to various network infrastructures. This feature ensures reliable communication channels, particularly in scenarios where wired connections pose challenges or limitations, thereby enhancing overall operational flexibility.Furthermore, the Fanvil Y501-Y Dubai offers versatile installation modes, including standard 86 box embedding and wall mounting options. This adaptability seamlessly integrates the intercoms into diverse architectural environments, addressing the specific requirements of each installation setting. By providing multiple installation options, Fanvil empowers users to effortlessly incorporate these advanced communication systems into their existing infrastructure, thereby enhancing efficiency and effectiveness across healthcare facilities.

The Fanvil Y501-Y Dubai SIP healthcare intercoms symbolize the epitome of innovation and functionality in healthcare communication technology. With their robust features, versatile installation options, and unwavering commitment to quality and reliability, these intercom systems are poised to revolutionize healthcare communication, setting a new standard for excellence in patient care and safety.


  • Support audio codec G.722 and Opus.
  • Support specific 433MHz wireless button
  • Features 2 SIP accounts and 6 antibacterial material detachable function buttons
  • Support HD audio with codec G.722 and Opus
  • Built-in 2.4G&5G Wi-Fi(Y501W-Y/Y501W-Y-E)
  • Built-in 1 short circuit input/output interface
  • IP54 waterproof and dustproof
  • Support PoE power supply
  • Support wall mountable installation (Y501-Y/Y501W-Y) and 86 box embedded installation(Y501-Y-E/Y501W-Y-E)



  • 2 SIP Lines
  • Auto answer
  • HD Voice
  • PoE Enabled
  • Built-in 2.4GHz & 5G Wi-Fi(Y501W-Y/Y501W-Y-E)
  • Intercom function
  • External Power Supply (Optional)

Intercom Function

  • Support customized DSS keys
  • Support wireless button (Optional)
  • Network Time Synchronization
  • Built-in Wi-Fi
    • 2.4G, 802.11 b/g/n
    • 5G, 802.11 a/n
  • Action URL / Active URL


  • Narrowband Codec : G.711a/u, G.729AB, G.723.1, G.726, iLBC
  • Wideband Codec : G.722, Opus
  • Duplex intercom with Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer up to 300ms
  • DTMF : In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO


  • Physical : 10/100 Mbps Ethernet
  • WIFI : 2.4G & 5G (Y501W-Y/Y501W-Y-E)
  • IP Mode : IPv4/IPv6/IPv4&IPv6
  • IP Configuration : Static / DHCP / PPPoE
  • Wi-Fi Encryption : WPA /WPA2-PSK /802.X EAP
  • VPN : L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS


  • SIP2.0 over UDP/TCP/TLS
  • STUN
  • DHCP
  • IPv6
  • LLDP
  • PPPoE
  • L2TP
  • OpenVPN
  • SNTP
  • TR-069

Physical Specifications

  • Y501-Y Series : 6 DSS buttons (Finish, Nursing, Assistant, Call,Dressing change, Infusion)
  • Up to 10 wireless buttons supported
  • Status indicator light : Red(registration failed、network anomaly)、Green(registration successful、call)
  • 1 RJ45 port
  • 1 short circuit input interface
  • 1 relay : NC/NO Contacts, Max DC30V/1A, AC125V/0.5A
  • Power : DC12V/1A or POE
  • Power Consumption (Adapter):
    • 0.94W~1.98W(Y501-Y/Y501-Y-E)
    • 1.42W~2.35W(Y501W-Y/Y501W-Y-E)
  • Power Consumption (PoE):
    • 1.48W~2.37W(Y501-Y/Y501-Y-E)
    • 1.99W~3.05W(Y501W-Y/Y501W-Y-E)
  • Housing material : ABS
  • 433 wireless button specification:
    • communication mode:FSK
    • working frequency:433MHZ
    • communication protocol:Ebelong1.1
  • Installation : Indoor installation
    • Standard 86 Box Embedded
    • Wall Mountable
  • Color : White
  • working temperature : -10 ~50 °C
  • Storage temperature : -20 ~ 50 °C
  • Relative humidity : 10% – 90%
  • N.W/CNT:3.97kg
  • G.W/CNT:4.4 kg
  • Equipment Dimension :
    • 87.56 x 87.56 x 30mm (Wall Mountable)
    • 87.56 x 87.56 x 21.5mm (86 Box Embedded)
  • Packing Dimension : 234x168x44 mm
  • Outer CTN Dimension : 356x245x254mm (10pcs)
