Tplink CPE510 Outdoor Radio Dubai
The Tplink CPE510 Dubai is an outdoor CPE that posses 5GHz 300Mbps 13dBi .It is cheap for outdoor networking solutions with the aid of its centralized management application. Its also flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users. Tplink CPE510 Dubai comes equipped with centralized management software that helps users easily manage all the devices in their network from a single PC – Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
Features
- Tplink CPE510 Dubai has built-in 13dBi 2×2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 26dBm/200mw
- System-level optimizations for more than 15km long range wireless transmission
- Tplink Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Tplink CPE510 Dubai comes with a Centralized Management System – Pharos Control
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- Tplink CPE510 Dubai is supplied with a Passive PoE Adapter which supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely.
Technical Specifications
| HARDWARE FEATURES | |
| Processor | Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc |
| Memory | 64MB DDR2 RAM, 8MB Flash |
| Interface |
|
| Power Supply |
|
| Power Consumption | 10.5 Watts Max Note : When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. |
| Dimensions ( W x D x H ) | 8.8 x 3.1 x 2.4 in |
| Antenna Type |
|
| Protection |
|
| Enclosure |
|
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11a/n (with Pharos MAXtream disabled) |
| Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds |
|
| Frequency | 5.15~5.85GHz Note : Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used. |
| Transmission Power | 23dBm/200mw (Adjustable power by 1dBm) Note : Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used. |
| POE ADAPTER FEATURES | |
| Dimensions(W x D x H) | 4.3 x 2.2 x 1.3 in |
| Interfaces |
|
| Button | Remote Reset Button |
| Power Status LEDs | Green |
| Input | 100-240VAC, 50/60Hz |
| Output | 24VDC, 1A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) |
| Efficiency | >80% |
| Certifications | CE/FCC |
| OTHERS | |
| Certification | FCC, RoHS, IPX5 |
| Package Contents |
|
| System Requirements | Google Chrome, Safari, and Firefox browsers for web GUI management |
| Environment |
|
