Tplink TL-SL2428P Dubai

Description

Tplink TL-SL2428P Network Switch Dubai

Enhance your business with power-over-Ethernet (PoE) devices, such as IP security cameras, access points, VoIP phones, and more, with the JetStream Tplink TL-SL2428P Dubai V4 24-Port 10/100 Mb + 4-Port Gigabit PoE+ Compliant Managed Network Switch from TP-Link. Its twenty-four 10/100 Mb/s ports are PoE+ compliant with a total power budget of 250W, allowing you to operate a variety of compatible devices and configure a comprehensive surveillance system.

The JetStream Tplink TL-SL2428P Dubai also includes four Gigabit Ethernet ports for provide high-speed connections to computers and other non-PoE devices in addition to four Gigabit RJ45/SFP combo ports for uplink connections. With a 12.8 Gb/s switching capacity, 9.5 Mpps forwarding rate, and abundant layer 2 features, this switch is designed to provide smooth data transfer, voice, and streaming video performance. The JetStream TL-SL2428P V4 may be configured and managed using either a web-based or command line interface.

Features

Advanced QoS Features

Administrators can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority, and DSCP Priority, to ensure that voice and video are always clear, smooth, and jitter-free. In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance.

Storm Control

The Storm Control feature protects against broadcast, multicast, and unknown unicast Storm.

Abundant Layer 2 Features

The Tplink TL-SL2428P Dubai supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, port isolation, port mirroring, STP/RSTP/MSTP, link aggregation grouping, and 802.3x flow control. Advanced network maintenance features include loop back detection, cable diagnostics, and IGMP snooping. IGMP snooping ensures the switch intelligently forwards the multicast stream to only appropriate subscribers while IGMP throttling and filtering restrict each subscriber on a port level to prevent unauthorized multicast access.

Enterprise Level Management

The Tplink TL-SL2428P Dubai network switch supports various user-friendly standard management features, such as ab intuitive web-based Graphical User Interface (GUI) or standard Command Line Interface (CLI). SNMP v1/2/3 and RMON support enable the switch to be polled for valuable status information and send traps on abnormal events.

Technical Specs

Interfaces
Ports	24 x 10/100 Mb/s Ethernet (RJ45) PoE+ 4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 2 x 10/100/1000 Mb/s Gigabit Combo (Ethernet/SFP) (Uplink)
Protocols
Layer Services Supported	Layer 2 Support, Layer 3 Support, Layer 4 Support
Supported Protocols	Auto-MDIX/MDI IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring RADIUS SNMPv1 SNMPv2c SNMPv3
Queuing	Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support	9216 Bytes
MAC Address Table Size	8K
VLAN Groups	4000
Security
Security Features	DoS Attack Prevention RADIUS Authentication Storm Control
Access Control List	230
SNMP Support	1, 2c, 3
Standards
Supported IEEE Standards	802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3i, 802.3u, 802.3x, 802.3z
Performance
Forwarding Rate	9.5 Mpps
Switching Bandwidth	12.8 Gb/s
Priority Queues	8
Computer
OS Compatibility	Windows Windows NT macOS UNIX Linux
Electrical
Power Draw	286.7 W (Max)
PoE Power Budget	250 W
PoE per Port	30 W
Environmental
Operating Temperature	32 to 122°F / 0 to 50°C
Operating Humidity	10 to 90%
Storage Temperature	-40 to 158°F / -40 to 70°C
Storage Humidity	5 to 90%
General
Cooling System	Fan
Rack Form Factor	1 RU
Dimensions	17.3 x 7.1 x 1.7″ / 440 x 180 x 44 mm
Packaging Info
Package Weight	6.57 lb
Box Dimensions (LxWxH)	21.1 x 10.1 x 3.2″
