Description
Tplink TL-SG1218MPE Network Switch Dubai
Expand your office or business network capacity with the Tplink TL-SG1218MPE Dubai JetStream 16-Port Gigabit PoE+ Compliant Managed Switch with SFP from TP-Link. This managed switch features 16 PoE+ compliant Gigabit Ethernet ports with a 36 Gb/s switching capacity and a 23.8 Mbps forwarding rate for fast and efficient data transfers. Each port supports up to 30W of power, with a total power budget of 192W to operate compatible devices such as IP security cameras, outdoor antennas, network attached storage, and more. The switch’s built-in power management system will automatically turn off lower priority ports to ensure high-priority devices remain powered and to protect against power overload. There are also two SFP ports for fiber lines and expansion.
Network administrators can take advantage of QoS tools to prioritize and optimize traffic. The web-based utility also allows you to monitor traffic in addition to other services. Two fans help to maintain temperatures and performance. The Tplink TL-SG1218MPE Dubai includes a rack mounting kit, but it may also be mounted on a desktop.
Features
Ideal for Surveillance
Tplink TL-SG1218MPE Dubai complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget is up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.
Intelligent Power Management
When total power consumption excels 192W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Making Management Easy
Tplink TL-SG1218MPE Dubai offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG1218MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
Each of the 16 PoE+ compliant Gigabit Ethernet ports supports up to 30W of power, with a total budget of 192W. Two SFP ports are available for fiber lines.
Fast Speeds
The Tplink TL-SG1218MPE Dubai has a 36 Gb/s switching capacity and a 23.8 Mbps forwarding rate.
Intelligent Power Design
A built-in power management system automatically shuts down low-priority devices to keep high-priority devices powered and protect against overloads.
Easy Network Management
Use the web-based management utility to monitor and optimize network traffic performance.
Technical Details
| HARDWARE FEATURES | |
| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p | |
| Interface | 16 10/100/1000 Mbps RJ45 Ports |
| (Auto Negotiation/Auto MDI/MDIX) | |
| 2 Gigabit SFP Ports | |
| Network Media | 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 100BASE-TX : UTP category 5, 5e cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 1000BASE-T : UTP category 5, 5e, 6 or above cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 1000BASE-X MMF, SMF | |
| Fan Quantity | 2 Fans |
| Physical Security Lock | Yes |
| Power Supply | 100-240V AC, 50/60 Hz |
| PoE+ Ports(RJ45) | Standard : 802.3at/802.3af compliant |
| PoE+ Ports : 16 Ports | |
| Power Supply : 192W | |
| Dimensions ( W x D x H ) | 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) |
| Mounting | Rack Mountable |
| Max Power Consumption | 18.73 W (220/50Hz. no PD connected) |
| 217.22 W (220/50Hz. with 192W PD connected) | |
| Max Heat Dissipation | 63.89 BTU/h (no PD connected) |
| 741.15 BTU/h (with 192W PD connected) | |
| PERFORMANCE | |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 23.8 Mbps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4.1 Mbit |
| Jumbo Frame | 9 KB |
| SOFTWARE FEATURES | |
| Quality of Service | Support Port-based 802.1p/DSCP priority |
| Support 4 priority queues | |
| Rate Limit | |
| Storm Control | |
| L2 Features | IGMP Snooping V1/V2/V3 |
| Static Link Aggregation | |
| Port Mirroring | |
| Cable Diagnostics | |
| Loop Prevention | |
| VLAN | Support up to 32 VLANs simultaneously (out of 4K VLAN IDs) |
| MTU/Port/Tag VLAN | |
| Management | Web-based GUI |
| Easy Smart Configuration Utility | |
| Transmission Method | Store-And-Forward |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | TL-SG1218MPE |
| Power Cord | |
| Installation Guide | |
| Resource CD | |
| Rackmount Kit | |
| Rubber Feet | |
