The PTC330U AI Auto Tracking PTZ Camera is designed to give you the best experience in audio and video capturing. It runs on Microsoft Windows 7.0 or later version, and is configured to support various network security protocols such as  IPv6, IPv4, TCP, UDP, ARP, IMCP, IGMP, HTTP, DHCP, RTP/RTCP, RTSP, RTMP, and VISCA over IP.

Description

Aver PTC330U Dubai

The Aver PTC330U in Dubai comes in two colors : grey and white, therefore enabling you to choose one that you prefer. It is elegantly designed to achieve the prime focal point of any room. The wall mountable camera is supplied with a ceiling mount that enables a user to mount it on a wall, resulting in a cleaner and neater workspace.

The Aver PTC330U in Dubai zooms, pans, and tilts effectively to provide you with high quality and crystal clear images during presentations, content streaming, broadcasting, as well as conferences. An optical zoom of 30X and a 4K resolution of 1080p delivers breathtaking images. The Aver PTC330U in , Dubai boasts of high auto tracking abilities, and is suitable for use in medical facilities, businesses, as well as classrooms.

AVer’s SmartFrame technology which is incorporated into the Aver PTC330U offers the user one-touch face targeting optics to help capture stunning content within the shortest time possible. SmartFrame automatically adjusts the FoV to include everyone on the screen, giving you quick turnaround time to record conferences, lectures and presentations with minimum effort.

Aver PTC330U Features :

  • 4K Resolution
    • The camera on the PTC330U has a 4K output, on top of auto-tracking precision and Ultra High Definition resolution of 1080p resulting in crystal clear images. The inbuilt Sony sensor offers users next-level video performance for every frame of the production, complete with auto exposure, autofocus, and auto white balance.
  • Human Detection Artificial Intelligence
    • Move into the future of video recording with AVer’s advanced technology of Artificial Intelligence; Human Detection. This smart algorithm is not only accurate but also able to easily detect and capture human subjects and moving objects within the room, all this in seconds. With this intelligence, you can be guaranteed to never lose track of a target again.
  • Zooming Performance
    • The AVer PTC330U has a zooming power of up to 60× (30× optical zoom and 2× sensor zoom). Even when the camera is panning and tilting, it works efficiently to allow you to highlight content and randomly change your shooting angles. The AVer PTC330U has been designed to let you enjoy clear video content, even when images are zoomed in to maximum angle, minus motion blurs or pixilation.
  • Instant Focus Redirect
    • The Aver PTC330U enables you to redirect focus by simply clicking on a target to quickly adjust the shooting angle and start your tracking process. All this has been made easy as you can operate through the remote control or Web UI.
  • Freedom to Interact
    • The camera’s presenter mode enables you to easily track your target everywhere. The Aver PTC330U affords the one leading the meeting unlimited freedom to move around the room and interact with the audience without fear of being out of focus as the camera continuously tracks subjects. The camera focuses on its target, ignoring other distractions during your presentation, which frees you from having to sit in the same position throughout.
  • Multi-Display Capture
    • The AVer PTC330U camera has a Zone Mode feature which improves your ability to capture content on multiple displays. This gives you the option of creating up to four content zones, with a focus on the displayed content rather than the presenter’s movements.
  • Impressive 255 Preset Locations
    • On top of the 10 preset locations that can be achieved via the IR remote control, you can capture a wide variety of angles as well as shift the recording view in an instant, thanks to the 255 preset location onboard the AVer PTC330U. This is made possible through VISCA via RS232 and RS422 functionalities. Furthermore, the AVer SmartShoot technology offers you maximum camera control to enable seamless transitions between the preset areas. This gives you the ability to run multi-camera productions linking into the same PTC330U thereby saving you time and effort while enjoying unparalleled shooting dynamics.
  • Motion Control Stability
    • With the freedom to customize speed settings from 0.1°to 200° per second, giving you maximum precision and agility with controls like panning, tilting and rotation.
  • Instant Field of View Adjustment
    • Infused with AVer’s SmartFrame technology, the PTC330U offers the user one-touch face targeting optics to help you capture stunning content within the shortest time possible. SmartFrame automatically adjusts the FoV to include everyone on the screen, giving you quick turnaround time to record conferences, lectures and presentations with minimum effort. With the PTC330U, creating amazing video content is now easy, quick, and enjoyable.

Aver PTC330U Specification :

Image Sensor 1/ 2.5″ 4K Exmor CMOS
Effective Picture Elements 8 megapixels
Output Resolutions 4K/30, 4K/29.97,

4K/25, 1080p/60,

1080p/59.94,

1080p/50,1080p/30,

1080p/29.97,

1080p/25,1080i/60, 1080i/50,720p/60,

720p/59.94,720p/50

Minimum Illuminations 2.7 lux (IRE50, F 1.5, 30fps)
S/N Ratio ≥50dB
Gain Auto, Manual
TV Line 1400 (center)
Shutter Speed 1/1 to 1/32000 sec
Exposure Control Auto, Manual, Priority AE (Shutter, Iris), BLC, WDR
White Balance Auto, Manual
Optical Zoom 30 ×
Digital Zoom 12 ×
Sensor Zoom 2 ×
Viewing Angles DFOV: 75°(Wide) to 3°(Tele)

HFOV: 68° (Wide) to 2.8° (Tele)

VFOV: 40° (Wide) to 1.6°(Tele)

Focal Length f = 4.8mm (Wide) to 144mm (Tele)
Aperture (Iris) F = 1.5mm (Wide) to 3.4mm (Tele)
Minimum Working Distance 1.5m to infinity
Pan/Tilt angles Pan: ±170°

Tilt: 90°/ -30°

Pan/Tilt speed (manual) Pan: 0.1° to 100°/sec

Tilt: 0.1° to 100°/sec

Preset Speed Pan: 200°/sec, Tilt: 200°/sec
Preset Positions 10 (IR), 256(RS -232)
Camera Control – Interfaces RS -232 (DIN8), RS – 422(RJ45), IP
Camera Control – Protocols VISCA, PELCO – D (RS -232/RS – 422/IP), CGI (IP)
Image Processing Noise reduction (2D/3D), Flip, Mirror
Power Frequencies 50Hz, 60 Hz
Tracking Modes Presenter Mode, Zone Mode
Channel 2 channels (Stereo)
Codecs AAC – LC (48/44.1/32/24K), G.711, PCM(8K)
Sample Rates 48/44.1/32/24/16/8kHz
Video Outputs 3G – SDI, HDMI, IP, USB
Audio Outputs 3G – SDI, HDMI, IP, USB
Audio Inputs MIC in, Line in
Power Requirement AC100V – AC240V to DC12V/5A
Power Consumption 18W
PoE PoE
Dimensions (W × H × D) 180.0× 183.5 × 145.0mm
Net Weight 1.7(±0.1) kg
Application Indoor
Tally Lamp Yes
Security Kensington slot
Remote control Infrared
Operating Conditions Temperature: 0° to 40°C

Humidity :20% to 80%

Storage Conditions

Temperature: -20° to 60°C

Humidity: 20% to 95%

Resolution 4K 30 fps
Network Video Compress formats H.264, H.265 MJPEG
Maximum Frame Rates 4K 30fps or 1080p 60fps
Bit-rate Control Modes VBR, CBR (selectable)
Range of Bit-rate Setting 512Kbps to 32Mbps
Network Interfaces 10/100/1000 Base -T
Multi-Stream capability 2 (RTSP/web page), 1080p 60fps (max)
Network Protocols IPv6, IPv4, TCP, UDP, ARP, IMCP, IGMP, HTTP, DHCP, RTP/RTCP, RTSP, RTMP, VISCA over IP
NDI® |HX Capability Yes (optional)
Connector USB 3.0
Video Format MJPEG
Maximum Video Resolution 2160p
USB Video Class UVC1.1
USB Audio Class UAC1.0
Live Video Preview Yes
Camera PTZ control Pan, Tilt, Zoom, Focus, Preset control
Camera /Image adjustment Exposure, White balance, Picture
Network Configuration DHCP, IP address, Gateway, Subnet mask, DNS
IP Search & Configuration tool Support Windows® 7 or later



What’s in the Box :

  • The Aver PTC330U Camera
  • Remote control
  • Power Adapter
  • Power cord
  • Cable Ties (×5)
  • Screws (×10)
  • Cable Fixing Plates (×2)
  • Ceiling Mount Brackets (×2)
  • Quick Start Guide
