Aver VC520 Pro3 Dubai



Aver VC520 Pro3 Dubai

Experience the unparalleled capabilities of the Aver VC520 Pro3 Dubai, an advanced conferencing system distinguished by its cutting-edge features. With a 36X total zoom PTZ camera, sophisticated AVer SmartFrame technology, Preset Framing, and a Sony WDR sensor, this system ensures top-tier video and audio quality.

Description

Aver VC520 Pro3 Video Conferencing System Dubai

Experience the unparalleled capabilities of the Aver VC520 Pro3 Dubai, an advanced conferencing system distinguished by its cutting-edge features. With a 36X total zoom PTZ camera, sophisticated AVer SmartFrame technology, Preset Framing, and a Sony WDR sensor, this system ensures top-tier video and audio quality. Boasting three-way outputs, including HDMI connectivity, it provides versatile streaming options.

The standout feature of the Aver VC520 Pro3 Dubai is its Smart Composition function, an embedded AI feature that rapidly captures high-quality close-up images of meeting participants. Complementing its capabilities, the extended speakerphone solution guarantees exceptional video quality. Conduct seamless meetings using the Aver VC520 Pro3 Dubai PTZ lens, offering an expansive 80.5° diagonal field of view and versatile pan and tilt controls.

With a 12X optical lens and an impressive 36X total zoom, including 24X lossless zoom, the VC520 Pro3 ensures exceptional clarity in remote communication. The Sony WDR sensor adapts to various lighting conditions, making it ideal for mid-to-large conference rooms. Serving as a pioneering PTZ camera and audio system featuring Smart Composition, typically reserved for enterprise-grade devices, the Aver VC520 Pro3 Dubai stands out.

The AI-powered Smart Composition feature automatically frames each participant’s face or body perfectly, allowing seamless transitions between headshots and half-body views without the need for any software setup. Facilitating simultaneous 1080p/60fps presentations through HDMI and USB 3.1 streaming or RTSP/RTMP H.264 broadcasting, the Aver VC520 Pro3 Dubai enables the use of a second display or lecture recording system during virtual meetings. This connectivity ensures seamless hybrid meeting experiences for your business.

Specifications

Camera

Resolution : (16 : 9) 1920 x 1080, 1280 x720 at 60, 30, 15fps; 1600 x 900, 960 x 540, 848 x 480, 800 x 448, 640 x 360, 424 x240, 320 x 180 at 30, 15fps; (4 : 3) 1280 x 960, 800 x 600, 640 x 480, 480 x 360, 320 x 240 at 30,15fps

  • SmartFrame for automatic FOV adjustment to fit all participants.
  • Smart Composition function offers great visibility for the individual participant in the meeting room.

Innovative Preset Framing : Follow the presenter based on preset areas.

WDR : Superb backlight compensation technology for optimizing light balance in high-contrast conditions.

Zoom : 36X* total zoom (12X optical zoom)

Field of view(D/H/V) : 80.5°/72.8°/44.1°

Lens focal length : 3.9 mm (wide) ~ 46.8 mm (tele)

Lens F# : 1.6 (wide) ~ 2.8 (tele)

  • Mirror, flip, white balance : Auto/manual override via PTZApp 2
  • Minimum focus distance : 1m
  • Standard tripod screw holes and Kensington slot.

People-counting API : Enterprises and third-party software providers can obtain people-counting data for a better understanding of meeting space usage.

*Please use PTZApp 2 to set up 36X zoom.

  • Motorized Pan & Tilt Movement
  • Pan : ±170°
  • Tilt : +90° (up) -30° (down)
  • 10 camera presets (via remote control)
  • Fast and quiet pan/tilt movement

Video Format

  • YUV, YUY2, MJPEG
  • Network video compression format : H.264
  • Network protocol : RTSP, RTMP

Connectivity

  • 12V/5A power adaptor
  • Mini DIN9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)
  • USB 3.1 Type-B connector
  • IP (RJ45)
  • HDMI out

*An RJ45 port is provided for Speakerphone connectivity.

USB

  • 3.1 Gen 1 Type-B, backward compatible with USB 2.0
  • UVC (USB video class) 1.1
  • UAC (USB audio class) 1.0

Control

  • IR remote control
  • VISCA/Pelco-P/Pelco-D via RS232 (128 preset points via VISCA command)
  • Remote side : VISCA over IP, IP (RJ45)
  • UVC/UAC plug-and-play
  • WebUI : Browser IP access via Chrome (does not support Internet Explorer)
  • PTZApp 2

Mount

  • Camera wall-mount bracket included
  • Optional foldable TV mount
  • Optional ceiling mount

System Requirements

  • Windows® 7/10/11
  • Mac OS X 10.4 or later
  • Google Chromebox 3 version 94.0.4606.114 or later

PC Hardware Requirement

  • 3.2 GHz Intel® Core™ i5-4460 processor
  • 4 GB RAM or more
  • USB 3.1 port, backward compatible with USB2.0 port

Webpage Browser Requirement

  • Chrome : Version 76.x or above
  • Firefox : Version 69 or above
  • IE : Not support

Power Supply

  • AC 100V ~ 240V, 50/60 Hz
  • Consumption : 12V, 5A

Dimensions

  • Package dimensions : 259 x 259 x 349 mm
  • Package weight : 5.805 kg
  • Camera : 150 x 153 x 182 mm/1.83 kg
  • Speakerphone : 220 x 181.5 x 49.5 mm/0.85 kg
  • Remote control : 200 x 50 x 21 mm/0.09 kg
