Qnap TS869 Pro Dubai



Qnap TS-869 Pro Dubai

The Qnap TS-869 Pro Dubai Turbo NAS Server is an 8 bay, all-in-one NAS server with exceptional performance that can meet the storage requirements of modern SMB IT environments.

Description

Qnap TS869 Pro Dubai

The Qnap TS869 Pro Dubai Turbo NAS Server is an 8 bay, all-in-one NAS server with exceptional performance that can meet the storage requirements of modern SMB IT environments. It features a secure cross-platform file sharing for Windows, Mac and Linux/UNIX users. The NAS server also has an iSCSI or IP-SAN storage combo solution and a number of versatile, value-added business applications. The NAS server is an ideal shared storage solution for virtualized and clustered environments. It is VMware Ready and Citrix Ready certified. This has also proven compatible with Microsoft Hyper-V environments.

Features:

Cross-platform Sharing with Antivirus

The Qnap TS-869 Pro Dubai supports SMB/CIFS, NFS and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks. Your accounts and shared folders can be created via a user-friendly web based interface without IT expertise. The integrated antivirus solution for the Turbo NAS ensures business stability. It offers detection against the latest viruses, malware, worms and Trojan horses.

Windows Active Directory (AD) and LDAP Directory Service

The Windows AD and Lightweight Directory Access Protocol (LDAP) is a directory service feature that enables you to retrieve user accounts from Windows AD or LDAP based directory server to the Qnap TS-869 Pro Dubai. This reduces time and effort in setting up a new account. You can use the same login name and password to access the Turbo NAS.

Shared Folder Aggregation

You can access the shared folders of other servers on Microsoft Networking through the “portal folder” on the Qnap TS-869 Pro Dubai. This saves the time and effort in logging in multiple servers one by one.

ISO File Archiving and Sharing

With the Qnap TS-869 Pro Dubai you can mount ISO images of CD and DVD discs as network shares for data archiving, storage and sharing. This saves the space for storing the physical discs and reduces the risk of data loss caused by disc wear and tear. It also enhances the efficiency of data sharing on business network.

Advanced Folder Permissions

You can configure folder/subfolder access to the Qnap TS-869 Pro Dubai with advanced folder permissions. With this feature enabled, you can manage the folder permissions from Microsoft Windows or the web-based management interface of the Turbo NAS easily.

Secure Measures for Data Storage and Access

Policy based Unauthorized IP Blocking:
You can allow, deny or auto block specified IP address or network domain which attempt to connect to the Turbo NAS via SSH, Telnet, HTTP(S), FTP, Samba or AFP.

TS-869 Pro Turbo NAS Server Specs

Hardware
CPU Intel Atom 2.13 GHz Dual-core Processor
DRAM 1 GB RAM (Expandable RAM, up to 3 GB)
Flash Memory 512 MB DOM
Hard Disk Drive 2.5″ (63.49 mm) or 3.5″ (88.89 mm) SATA x 8
Hard Disk Tray 8 x Hot-swappable and lockable tray
LAN Port 2 x Gigabit RJ-45 Ethernet port
LED Indicators Status, LAN, USB, eSATA, Power, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5, HDD 6, HDD 7, HDD 8
USB 2x USB 3.0 port (Back: 2) 5x USB 2.0 port (Front: 1; Back: 4)
Supports USB printer, pen drive, USB hub and USB UPS etc.
eSATA 2 x eSATA ports (Back)
Performance Reading: 221.8 Mbps
Writing: 220.8 Mbps
Buttons Power button, USB One-Touch-Backup Button, Reset button
LCD Panel Mono LCD display with backlight
Enter button, Select button for configuration
Supply Type System warning
Form Factor Tower
Sound Level Without HDD installed: 40.0 dB
Stand by: 40.4 dB
In operation: 40.8 dB
(with 8 x 750 GB HDD installed)
Power Consumption Sleep mode: 30 W
In Operation: 59 W
Power-off (in WOL mode): 1 W
(with 8 x 1.5 TB HDD installed)
Power Supply Input: 100-240 V AC, 50-60 Hz
Output: 350 W
Secure Design K-lock security slot for theft prevention
Expansion Slot 1 (for network or storage expansion)
VGA Reserved VGA interface for maintenance
Fan Two 4.72″ (12 cm), 12 V DC cooling fan
General
Temperature 32 to 104˚F (0 to 40˚C)
Humidity 0-95% R.H.
Dimensions 7.29 x 11.74 x 9.26″ (185.2 x 298.2 x 235.4 mm)
Weight Net weight: 7.29 kg (16.08 lb)
Gross weight: 8.59 kg (18.94 lb)
Software
Operating System •Embedded Linux
Supported Operating System •Microsoft Windows 2000, XP, Vista (32 or 64 bit),7 (32 or 64 bit), Server 2003 or 2008
•Apple Mac OS X
•Linux and Unix
Supported Web Browsers •Internet Explorer 7, 8 or later
•Firefox 3 or later
•Safari 3, 4 or later
•Google Chrome
Multilingual Support •Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Norwegian, Polish, Russian, Spanish, Swedish, Turkish
File System •Internal HDD: EXT3, EXT4
•External HDD: EXT3, EXT4, NTFS, FAT32, HFS+
Networking •TCP/IP (IPv4 and IPv6: Dual Stack)
•Dual Gigabit LAN with Jumbo Frame
•Multi-IP settings, Port Trunking or NIC Teaming (Modes: Balance-rr, Active backup, Balance XOR, Broadcast, IEEE 802.3ad or Link Aggregation, Balance-tlb and Balance-alb)
•DHCP client, DHCP server
•Protocols: CIFS or SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSIand SNMP.
•Network Service Discovery(UPnP, Bonjour)
•Virtual LAN support
•USB Wi-Fi 802.11n adapter support (optional purchase)
Network File Sharing •CIFS/SMB (Plus DFS Support)
•AFP
•NFS
•FTP
•WebDAV
Backup Solution •Real-time Remote Replication (RTRR)
oWorks as Both RTRR server andclient
oSupports Real-time andscheduled backup
oSupports encryption, compression and file filter
•USB One Touch Backup (Import or export)
•Apple Time Machine Support with backup management
•Block-level Remote Replication
oWork as both Rsync server &client
oSupports encrypted replication between QNAP NAS servers
•Back up to external storage device
•Back up to Cloud Storage (Amazon S3 and ElephantDrive)
Security •IP filter andpolicybased automatic IP blocking
•Network Access Protection with auto-blocking
•Encrypted access: HTTPS, FTP with SSL or TLS (explicit), SSH or SFTP (admin only), Encrypted Remote Replication (Rsync over SSH)
•CIFS host access control for shared folders
•AES 256-bit volume-based encryption
•Importable SSL certificate
•Instant alert via email, SMS and LCD
Disk Management •Single disk, JBOD, RAID 0 / 1 / 5 /10/ 5+Hot spare / 6 /10
•Online RAID capacity expansion &online RAID level migration
•Bad Block Scan & HDD S.M.A.R.T
•Global Spare Drive
•AES 256-bit volume-based encryption
•RAID recovery
•Bitmap support
•Supports ISO mounting (via web file manager)
iSCSI (IP SAN) •iSCSI Target
oMulti-LUNs per target
oUp to 256 LUNs
oSupports LUN mapping & masking
oSupports SPC-3 persistent reservation
oSupports MPIO & MC/S
•Virtual Disk Drive (via iSCSI Initiator)
oStack Chaining Master
oMax. virtual disk drives: 8
oStorage plug and play client software to connect to iSCSI Target from PC
Server Virtualization & Clustering •Supports VMware vSphere (ESX or ESXi 4.x)
•Supports Citrix XenServer (5.6)
•Supports Windows server 2008 Hyper-V & failover clustering
Power Management •Wake on LAN
•Scheduled power on/off (Max 15 settings)
•Automatic power on after power recovery
Access Rights Management •Max user accounts: 4,096
•Max groups: 512
•Maxshare folder: 512
•Batch creating users
•Import or export users
•User quota management
•Subfolder permissions support
Windows AD Support •Domain users login via CIFS/SMB, AFP, FTP and web file manager
•Supports NTLM v2 authentication
Web Administration •AJAX-based user interface
•HTTP or HTTPS connections
•Alert notification (Email & SMS)
•Smart fan control
•DDNS & MyCloudNAS remote access
•SNMP (v2 & v3)
•UPS support with SNMP management (USB)
•Supports network UPS
•Resource monitor
•Network recycle bin for CIFS or SMB and AFP
•Comprehensive logs (Events andconnection)
•Real-time online user list
•Syslog client
•Firmware update with live update notification
•Backup and restore system settings
•Restore to factory default
Applications •Web file manager
•Multimedia station
•Download station
•Surveillance station
•Music station
•Photo station
•iTunes server
•UPnP media server
•Apache web server
•MySQL server
•VPN server
•LDAP server
QMobile App •QMobile for iPhone, iPad, iPod touch, Android devices
•Third party UPnP media player
QPKG •Web applications
oJoomla!
ophpMyAdmin
oWordPress
oAjaXplorer
ovtigerCRM
oGLPI
oMagento
•P2P Applications
oMLDonkey (eMule)
oSABnzbd+
oNZBGet
oTransmission
•Server Applications
oSqueezebox server
oTomcat
oAsterisk
oXDove (Mail server)
oOpenLDAP
oeyeOS
•Media Server
oPS3 media server
oIceStation
•Miscellaneous
oOptware IPKG
oPython
oJava Runtime Environment
oMono
oiStat
