Qnap TS1270U-RP Dubai



Qnap TS-1270U-RP Dubai

Qnap TS-1270U-RP boasts of 10GbE-ready which includes 2 in-built Gigabit Ethernet ports, which can be expanded with additional 2 Gigabit Ethernet ports, or 2 10Gigabit Ethernet ports.

Description

Qnap TS1270U-RP Dubai

Qnap TS1270U-RP Dubai is reliable with built-in safety precautions to safeguard all data from any unforeseen problems. The advanced RAID configurations and hot-swap capabilities are included to give RAID performance, protection and reduced rebuilding time. Moreover, the dual OS embedded on the DOM architecture ensures the system will boot up. If one of the two operating systems fails, the healthy operating system will boot up and operate normally while repairing the failed operating system. The dual Gigabit LAN ports can also be configured for failover which allows the NAS server to sustain the failure of one network port and still provide continuous services.

Key Features

Secure

Qnap TS-1270U-RP Dubai boasts of a variety of security options such as encrypted access, IP filtering, policy-based automatic IP blocking among other important security measures packed in this NAS server. Moreover, full control of the NAS is offered down to the user and folder access rights to determine authorized access. The server is loaded with AES-256 volume-based encryption. This feature stops sensitive data from being accessed by unauthorized users, and also prevents data-breach, even in the event that the hard drive(s) or device is stolen.

Reliable

Qnap TS-1270U-RP Dubai is reliable with built-in safety precautions to safeguard all data from any unforeseen problems. With multiple built-in features to guarantee no interruptions to the work flow of a business. The sophisticated RAID configurations and hot-swap capabilities are included to offer RAID performance, protection and minimized rebuilding time. Moreover, it has dual OS embedded on the DOM architecture makes sure that the system boots up. In the event that 1 of the 2 operating systems fails, the healthy OS will boot up and operate normally while repairing the failed one. The dual Gigabit LAN ports are also configurable for failover, allowing the NAS server to sustain one network port failure and continue to provide continuous service

Advanced folder permissions

Advanced folder permissions allow users to configure folder/subfolder access to the Qnap TS-1270U-RP Dubai. With this feature enabled, users can manage the folder permissions from Microsoft Windows or the web-based management interface of the TS-1270U-RP without complicated procedures. Qnap TS-1270U-RP Dubai is cost effective and does not require any IT skills.

Simple Installation

Installation processes is simplified to the point where most of the necessary steps are either automatic or may be completed via an installation wizard. The user-friendly web GUI enables administrators to easily manage the NAS without extensive knowledge of complicated commands. Easy management tools like instant SMS / Email alert, the hard drive S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) feature, and system resource monitor are included to keep administrators up-to-date on their NAS at all times10GbE-ready TS-1270U-RP includes 2 in-built Gigabit Ethernet ports, which can be expanded with additional 2 Gigabit Ethernet ports, or 2 10Gigabit Ethernet ports and delivers excellence performance with 1,000 MB/s throughput and 100,000 IOPS, improving the efficiency of virtualization applications via both NFS and iSCSI protocols. Coupled with the support for large storage capacity, the TS-1270U-RP is a perfect choice for applications demanding high storage space and transmission speed such as data centers storing big data and for studios editing 4K/HD videos on-the-fly without transferring the videos between the TS-1270U-RP and desktop computers

Flexible 10GbE network expansion

Qnap TS-1270U-RP boasts of 10GbE-ready which includes 2 in-built Gigabit Ethernet ports, which can be expanded with additional 2 Gigabit Ethernet ports, or 2 10Gigabit Ethernet ports and delivers excellence performance with 1,000 MB/s throughput and 100,000 IOPS, improving the efficiency of virtualization applications via both NFS and iSCSI protocols. Coupled with the support for large storage capacity, the TS-1270U-RP is a perfect choice for applications demanding high storage space and transmission speed such as data centers storing big data and for studios editing 4K/HD videos on-the-fly without transferring the videos between the TS-1270U-RP and mobile devices

Policy-based unauthorized IP blocking

The administrator can allow, deny or auto block specified IP address or network domain which attempt to connect to the Qnap TS-1270U-RP Dubai via SSH, Telnet, HTTP(S), FTP, Samba, or AFP.

Remote login

Qnap TS-1270U-RP Dubai supports remote login by SSH (secure shell) or Telnet connection.

Secure FTP

Qnap TS-1270U-RP Dubai offers secure data transfer with SSL/TLS (explicit) encryption. Passive FTP port range setup is also supported.

Shared folder management

Administrator can select to hide or show the network shared folders of the TS-1270U-RP on Windows network.

User authority management

Administrator can create user ID and password, and define the authority and quota for each user.

Failover

The LAN ports of the Turbo NAS can be configured in failover mode which allows the TS-1270U-RP to sustain the failure of one network port and provide continuous services.

Load balancing

The LAN ports of Qnap TS-1270U-RP Dubai can be configured in load balancing mode for bandwidth aggregation to boost file transfer speeds. It works with managed Ethernet switch with 802.3ad configured.

Multi-IP settings

Qnap TS-1270U-RP Dubai can be deployed with multiple different IP settings for sharing among different workgroups in two different subnets.

Ultra high Performance

The Qnap TS-1270U-RP Dubai is designed to provide IP SAN/NAS unified storage for large-scale business organizations that demand uncompromising high performance. Featuring a powerful Intel® Core™ i3-3220 Dual Core Processor, 4GB DDR3 RAM (expandable to 32GB), and the capacity to hold up to 12 hard drives, Qnap TS-1270U-RP greatly enhances efficiency of CPU-consuming tasks, powering large amount of concurrent tasks, and meeting the stringent requirements of data-hungry applications

NAS + iSCSI / IP-SAN Solution for Server Virtualization

Qnap TS-1270U-RP Dubai provides class-leading system architecture paired with 10 GbE networking performance engineered to meet the requirements of demanding server virtualization–including VMware, Citrix, and Windows Hyper-V. The 10 GbE network speeds greatly enhance the agility of data transmission in a virtualized environment, improving NFS and iSCSI connection performance.

High Network Bandwidth

Qnap TS-1270U-RP Dubai provides network expansion options, including dual-port 1 GbE and dual-port 10 GbE network expansion cards, to aggregate and improve network performance. The TS-EC1279U-RP features 2x Gigabit (GbE) LAN ports, expandable to 4x GbE LAN, or 2x 10 GbE LAN plus 2x GbE ports.

ECC RAM for High Reliability

Qnap TS-1270U-RP Dubai is equipped with ECC (Error Correction Codes) RAM of the Turbo NAS is capable of detecting and correcting errors that are introduced during data transmission or storage. It provides greater protection in mission critical applications.

Cross-platform Sharing with Antivirus

Qnap TS-1270U-RP Dubai is compatible SMB / CIFS, NFS, and AFP protocols for file sharing across Windows, Mac, and Linux / UNIX networks. User accounts and shared folders may be generated with the user-friendly web-based interface–no IT expertise required! The integrated antivirus solution for the Turbo NAS makes sure business workflow remains continuous by providing detection against the latest viruses, malware, worms and Trojan horses.

Windows Active Directory (AD) and LDAP Directory Service

Windows AD and LDAP (Lightweight Directory Access Protocol) directory service features allow the system administrator to retrieve user accounts from Windows AD or Linux LDAP server to the Qnap TS-1270U-RP Dubai, cutting down on time and effort in account setup. Users are permitted to use the same login name and password to access.

Shared Folder Aggregation

As an added convenience, you can connect to the shared folders of other servers on Microsoft Networking via the “portal folder” on Qnap TS-1270U-RP Dubai. This minimizes the hassle of logging in to various servers one by one.

ISO File Archiving and Sharing

Qnap TS-1270U-RP Dubai supports mounting of ISO images of CD / DVD discs for network sharing folders for data archiving, storage and sharing. This feature conserves way more space than does storing the physical discs, lowers the risk of data loss due to long-term use of the discs, and improves the performance of data sharing on a business network.

Centralized Log Monitoring

Qnap TS-1270U-RP Dubai features a central repository of log data from different network devices enables efficient business management and security auditing. QNAP Syslog server permits the IT administrator to collect and store logs of other network devices in the Turbo NAS.

Backup Center for Business

Qnap TS-1270U-RP Dubai delivers a total backup solution for businesses with QNAP QBack / NetBak Replicator, which supports real-time and scheduled data backup from Windows PCs, Apple Time Machine backup from Mac OS, and 3rd party backup software, including Acronis True Image and Symantec Backup Exec.

Disaster Recovery Solution, Real-time Remote Replication (RTRR)

Offers real-time or scheduled data replication between Qnap TS-1270U-RP Dubai and a remote QNAP NAS, FTP server, or external drive.

iSCSI LUN Backup and Restore

The Turbo NAS takes iSCSI LUN backup/ restore to a new level with snapshot technology. The IT administrator is now able to use the LUN snapshot to back up contents in the LUN to different storage destinations, such as Windows shared folders via SMB / CIFS, Linux shared folders via NFS, or local shared folders on the Turbo NAS.

Cloud Storage Backup

Qnap TS-1270U-RP Dubai provides support for Amazon S3 and ElephantDrive cloud storage backup, which feature several backup modes, such as real-time, scheduled backup and versioning control. This allows data to be restored from any point in time. With ElephantDrive, cloud storage may be monitored via web browser. An additional set of all of the data stored will always be available, making remote data recovery quick and easy.

NAS + iSCSI Combo Solution

Qnap TS-1270U-RP Dubai is capable of concurrently serving as a NAS for file sharing and iSCSI storage.

QNAP TS-1270U-RP Specs

Hardware Specification
CPU Dual-core Intel 2.4 GHz Processor
DRAM 4 GB DDR3 RAM
Flash Memory 512 MB DOM
Hard Disk Drive 12 x 3.5″ or 2.5″ SATA 6Gbps, SATA 3Gbps hard drive or SSD
Hard Disk Tray 12 x hot-swappable and lockable tray
LAN Port 2 x Gigabit RJ-45 Ethernet Port
(Expandable up to 6 x 1 Gb LAN or 4 x 10 Gb + 2 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card)
LED Indicators Status, 10 GbE, LAN, eSATA , hard drives
USB 2 x USB 3.0 port (rear)
4 x USB 2.0 port (rear)
(Support for USB printer, pen drive, USB hub and USB UPS etc.)
eSATA 2 x eSATA Port (rear)
Buttons System: Power button and reset button
Alarm Buzzer System warning
Expansion Slot 2 x (for network and storage expansion)
Fan 2 x Quiet Cooling Fan (7 cm, 12 V DC)
Sound Level Standby: 45.7 dB
In Operation: 46.7 dB
(with 12 x Hitachi HUA723020ALA640 MK7O installed)
Power Consumption Sleep Mode: 83.1 W
In Operation: 188.7 W
(with 12 x Hitachi HUA723020ALA640 hard drive installed)
Power Supply Input: 100 – 240 V AC, 47 – 63 Hz
Output: 500 W
Software Specification
Operating System Embedded Linux
Supported Clients Windows XP, Vista, Windows 7 (32/64-bit), Windows 8 (32/64-bit), Windows Server 2003/2008 R2/2012
Apple Mac OS X
Linux and UNIX
Supported Web Browsers Microsoft Internet Explorer 8, 9, 10
Mozilla Firefox 8+
Apple Safari 4+
Google Chrome
Multilingual Support Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
File System Internal Hard Drive: EXT3, EXT4
External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Networking TCP/IP (IPv4 & IPv6: Dual Stack)
Dual Gigabit NICs with Jumbo Frame
– Failover
– Multi-IP Settings
– Port Trunking/NIC Teaming (Modes: Balance-RR, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-TLB and Balance-ALB)
Optional Dual-port 10 GbE and 1 GbE Network Expansion Card
Service Binding based on Network Interfaces
Virtual LAN (VLAN)
Proxy Client
DHCP Client, DHCP Server
Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC
UPnP and Bonjour Discovery
USB Wi-Fi Adapter Support
Backup Solutions Real-Time Remote Replication (RTRR)
Works as Both RTRR Server and Client with Bandwidth Control
Real-time and Scheduled Backup
Encryption, Compression, File Filter and Transfer Rate Limitation
Block-level Remote Replication
Works as Both Rsync Server and Client with Bandwidth Control
Encrypted Replication between QNAP NAS Servers
Desktop Backup by QNAP NetBak Replicator for Windows
Apple Time Machine Support with Backup Management
Data Backup to Multiple External Storage Devices
Data Backup to Cloud Storage (Amazon S3, ElephantDrive, Symform and Google Drive)
Security IP Filter and Policy-based Automatic IP Blocking
Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH)
CIFS Host Access Control for Shared Folders
Antivirus Protection
FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption*
AES 256-bit External Drive Encryption*
Importable SSL Certificate
Instant Alert via E-mail, SMS, Instant Messaging (Windows Live), Beep and LCD Panel
Disk Management Single Disk, JBOD, RAID 0, 1, 5, 6, 10, 5 + Hot Spare, 6 + Hot Spare, 10 + Hot Spare
Global Hot Spare
Online RAID Capacity Expansion and Online RAID Level Migration
Bad Block Scan and Hard Drive S.M.A.R.T.
RAID Recovery
Bitmap Support
iSCSI (IP SAN) iSCSI Target with Multiple LUNS per Target (Up to 256 Targets/LUNs Combined)
LUN Mapping and Masking
Online LUN Capacity Expansion
Supports SPC-3 Persistent Reservation
Supports MPIO and MC/S
iSCSI LUN Backup, One-time Snapshot and Restore
iSCSI Connection and Management by QNAP Finder (Windows)
Stack Chaining Master: Up to 8 Virtual Disk Drives (via iSCSI Initiator)
Server Virtualization & Clustering Supports VMware vSphere (ESX/ESXi 4.x, ESXi 5.x)
Supports Citrix XenServer 5.x, 6.x
Supports Windows Server 2008 R2 and Windows Server 2012 Hyper-V
Supports Windows Server 2008 R2 and Windows Server 2012 Failover Cluster
Power Management Wake on LAN
Internal Hard Drive Standby Mode
Scheduled Power on/off (Max 15 Settings)
Automatic Power on after Power Recovery
USB and Network UPS Support with SNMP Management
Access Rights Management Max No. of Users: 4,096
Max No. of User Groups: 512
Max No. of Network Shares: 512
Batch Users Creation
Import/Export Users
User Quota Management
Local User Access Control for CIFS, AFP, FTP and WebDAV
Application Access Control for Photo Station, Music Station, Video Station and Multimedia Station
Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File Manager
Domain Authentication Integration Microsoft Active Directory (AD)
LDAP Server
LDAP Client
Domain Users Login via CIFS/SMB, AFP, FTP and Web File Manager
MyCloudNAS Service Private Cloud Storage and Sharing
Free Host Name Registration (DDNS)
Auto Router Configuration (via UPnP)
MyCloudNAS Connect for Easy VPN Connection (Windows VPN utility)
