The Qnap TS-1079 Pro Dubai offers a variety of security options to prevent unauthorized access to your data, even in the event that the hard drive or device is stolen.



Description

Qnap TS1079 Pro Dubai

Having been designed to deliver an exceptional performance, the Qnap TS1079 Pro Dubai provides large-scale business organizations  with a stable IP SAN/NAS unified storage solution. It is equipped with a powerful Intel® Core™ i3-2120 dual Core Processor, 2GB DDR3 RAM (expandable to 2GB), and the capacity to hold up to 10 hard drives, the TS-1079 Pro greatly enhances efficiency of CPU-consuming tasks, powering large amount of concurrent tasks, and meeting the stringent requirements of data-hungry applications.

The Qnap TS-1079 Pro Dubai NAS Server with 10GbE Network Ready Bundle is a server that functions as both IP-SAN (iSCSI) and NAS. It is easily employable in various business and enterprise applications, as a backup center and for disaster recovery, file sharing, virtualization and video editing storage.

The Qnap TS-1079 Pro Dubai offers a variety of security options to prevent unauthorized access to your data, even in the event that the hard drive or device is stolen. Sophisticated RAID configurations and hot-swap capabilities are present that offer high performance, protection and minimized rebuilding time. The dual OS embedded on the DOM architecture offers extra assurance that the system will boot up.

You can set up local or remote access with the server easily as it does not require IT skills. Simple management tools like instant SMS or Email alert, the hard drive S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) feature and system resource monitor are integrated to keep you up-to-date on your NAS at all times.

The system features an Intel Core i3 Processor, 2 GB DDR3 memory, 10 Gigabit network capability and a 6 GBps SATA interface for high performance and fast data transfer rates. It also provides fast data backup via USB 3.0.

The server supports SMB / CIFS, NFS and AFP protocols for file sharing across Windows, Mac and Linux or UNIX networks. There is a Real-Time Remote Replication (RTRR) between the system and a remote QNAP NAS, FTP server or external drive. It supports Amazon S3, ElephantDrive and Symform cloud storage backup. The built-in iSCSI feature offers an affordable IP-SAN (Storage Area Network) alternative for businesses.

The system provides AES 256-bit encryption. It functions as an all-in-one server, boasting file, FTP, backup, web, RADIUS, Syslog and print servers, as well as a surveillance station. It also features Multiple LAN deployment.

Features:

Flexible 10GbE network expansion

The 10GbE-ready TS-1079 Pro includes 2 in-built Gigabit Ethernet ports, which can be expanded with additional 2 Gigabit Ethernet ports, or 2 10Gigabit Ethernet ports and delivers excellence performance with 1,000 MB/s throughput and 100,000 IOPS, improving the efficiency of virtualization applications via both NFS and iSCSI protocols. Coupled with the support for large storage capacity, the TS-1079 Pro is a perfect choice for applications demanding high storage space and transmission speed such as data centers storing big data and for studios editing 4K/HD videos on-the-fly without transferring the videos between the TS-1079 Pro and desktop computers

Comprehensive virtualization support

The Qnap TS-1079 Pro Dubai is VMware® Ready™, Citrix® Ready™, compatible with Microsoft® Hyper-V™ certification and Windows Server 2012, and supports advanced functions including SPC-3, MPIO and MC/S, enabling flexible deployment and management for virtualization needs. The TS-1079 Pro supports VMware VAAI and Microsoft ODX to increase performance by offloading ESXi server loading, and supports QNAP vSphere Client plug-in and QNAP SMI-S provider to provide enhanced operational efficiency in managing virtualization applications.

High Efficiency with Multiple LAN support

The Qnap TS-1079 Pro Dubai supports multiple port-trunking modes, enabling IT administrators to set up link aggregation to increase total data transmission capability. Failover is also supported to ensure continuous system operations. The supported port-trunking modes include: Balance-rr (Round-Robin), Active Backup, Balance XOR, Broadcast, IEEE 802.3ad, Balance-tlb (Adaptive Transmit Load Balancing) and Balance-alb (Adaptive Load Balancing).

High stability. Built to last.

The Qnap TS-1079 Pro Dubaiserves as a business-ready system, providing 24/7 continuous operation and services. The dual OS embedded on the DOM architecture in the TS-1079 Pro ensures that the system boots up and operates stably. The expertly-designed smart fan delivers great system heat dissipation with minimum vibration, and is easily replaceable without system interruption. The TS-1079 Pro also features a redundant power supply to ensure maximum system uptime.

High reliability

The TS-1079 Pro supports comprehensive RAID configuration and hot-swapping to allow hard drive replacement without system interruption. QNAP’s advanced RAID recovery technology also helps if any healthy drives are removed from a degraded RAID volume by mistake. The system can be recovered to degraded mode by reinserting the wrongly removed hard drives so the data can still be accessible. The Global Hot Spare function also enables the global hot-spare drive to automatically replace a failed drive in a RAID volume, preventing data from being lost.

Large capacity for cross-platform sharing

The Qnap TS-1079 Pro Dubai supports large storage capacities; fulfilling business needs to store large amounts of data. It also supports comprehensive RAID management, online RAID capacity expansion, and flexible RAID migration to safely store important data therefore reducing the risks of data loss. With reliable data protection, the TS-1079 Pro is perfect for cross-platform data sharing. The support of Windows AD and LDAP Directory Service saves a great amount of time for account management and authentication. Users can use their Windows AD or LDAP server accounts and passwords to log into the Turbo NAS. The TS-1079 Pro can also serve as an LDAP server.

QNAP TS-1079 Pro Specs

Hardware
CPU Dual Core Intel Core i3-2120 Processor 3.3 GHz
DRAM 2 GB DDR3 RAM
Flash Memory 512 MB DOM
Hard Drive 10x 3.5″ (88.89 mm) SATA 6 GBps, SATA 3 GBps hard drive or 2.5″ (63.49 mm) SATA, SSD hard drive*
Hard Drive Trays: 10x hot-swappable and lockable
LAN Port 2x Gigabit RJ-45 Ethernet ports
Optional dual-port 10 Gb and 1Gb network cards are supported
USB 2x USB 3.0 ports (front: 1 ; rear: 1)
4x USB 2.0 ports (rear)
Supports USB printer, pen drive, USB hub, USB UPS and more
eSATA 2 (rear)
LED Indicators Status, LAN, USB, eSATA, 10GbE, hard drives
Buttons System: Power button, USB one touch backup button and reset button
LCD Panel Mono-LCD display with backlight
Enter and select buttons for configuration
Expansion Slot 1 (for network or storage expansion)
VGA Reserved for system maintenance
Fan 2x 4.72″ (12 cm) 12 V DC smart cooling fan
Supply Type System warning
Sound Level With 10x 1 TB hard drives installed:
Standby: 28.87 dB
In operation: 30.4 dB
Power Consumption With 10x 1 TB hard drives installed:
Sleep mode: 40 W
In Operation: 121 W
Power Supply Input: 100 – 240 V AC, 50 – 60 Hz
Output: 350 W
Form Factor Tower
Software
Operating System Embedded Linux
Supported Operating System Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2
Apple Mac OS X
Linux and UNIX
Supported Web Browsers Microsoft Internet Explorer 8, 9
Mozilla Firefox 8, 9, 10
Apple Safari 4, 5
Google Chrome
Language Support Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
File System Internal Hard Drive: EXT3, EXT4
External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Networking TCP/IP (IPv4 and IPv6: Dual stack)
Multiple Gigabit NICs with jumbo frame
-Failover
-Multi-IP settings
-Port trunking/NIC teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
Service binding based on network interfaces
Virtual LAN (VLAN)
DHCP client, DHCP server
Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC
UPnP and bonjour discovery
USB Wi-Fi adapter support
Backup Solution Real-Time Remote Replication (RTRR)
-Works as both RTRR server and client with bandwidth control
-Real-time and scheduled backup
-Encryption, compression, file filter and transfer rate limitation
Block-Level Remote Replication
-Works as both Rsync Server and client with bandwidth control
-Encrypted replication between QNAP NAS servers
USB one touch backup (import or export)
Desktop backup by QNAP NetBak replicator for Windows
Apple Time Machine support with backup management
Data backup to multiple external storage devices
Data backup to Cloud Storage (Amazon S3, ElephantDrive and Symform)
Security IP Filter and policy-based automatic IP blocking
Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), encrypted remote replication between QNAP NAS servers (Rsync over SSH)
CIFS host access control for shared folders
Antivirus protection
FIPS 140-2 validated AES 256-bit volume-based data encryption*
AES 256-bit external drive encryption*
Importable SSL certificate
Instant alert via email, SMS, instant messaging (Windows Live Messenger) and buzzer
Disk Management Single Disk, JBOD, RAID 0, 1, 5, 5+Hot-Spare, 6, 6+Hot-Spare, 10, 10+Hot-Spare
Online RAID capacity expansion and online raid level migration
Bad block scan and hard drive S.M.A.R.T.
Global hot-spare drive
RAID recovery
Bitmap support
iSCSI (IP SAN) iSCSI target
-Multi-LUNs per target
-Up to 256 targets/LUNs combined
-Supports LUN mapping and masking
-Online LUN capacity expansion
-Supports SPC-3 persistent reservation
-Supports MPIO and MC/S
iSCSI LUN backup, one-time snapshot and restore
iSCSI connection and management by QNAP finder (Windows)
Virtual disk drive (via iSCSI initiator)
-Stack chaining master
-Max. no. of virtual disk drives: 8
Server Virtualization and Clustering Supports VMware vSphere
Supports Citrix XenServer
Supports Windows Server 2008 R2 Hyper-V and failover clustering
Power Management Wake on LAN
Internal hard drive standby mode
Scheduled power on/off (max. 15 Settings)
Automatic power on after power recovery
USB and network UPS support with SNMP management
Access Rights Management Max. No. of Users: 4,096
Max. No. of User Groups: 512
Max. No. of Network Shares: 512
Batch users creation
Import/export users
User quota management
Subfolder permissions support for CIFS/SMB, AFP, FTP and web file manager
Domain Authentication Integration Microsoft Active Directory (AD)
LDAP server
LDAP client
Domain users login via CIFS/SMB, AFP, FTP and web file manager
MyCloudNAS Service Private Cloud Storage and sharing
Free host name registration (DDNS)
Auto router configuration (via UPnP)
MyCloudNAS connect for easy connection (Windows utility)
Storage Plug & Play Windows Software: QNAP finder
Create and map shared folders
Create and connect to iSCSI target/LUN
Web Administration AJAX-based user interface
Smart fan control
Dynamic DNS (DDNS)
SNMP (v2 and v3)
Resource monitor
Network recycle bin for file deletion via CIFS/SMB and AFP
Comprehensive logs (Events and connection)
Syslog client
Firmware live update
System settings backup and restore
Restore to factory default
Powerful All-in-one server
File Server File sharing across Windows, Mac and Linux or UNIX
Shared folder aggregation (CIFS/SMB)
Web file manager
-Supports ISO mounting
-Direct file viewing via Google doc
-Create and send download links for public file sharing with expiration time and password protection
FTP Server FTP over SSL/TLS (explicit)
Max. No. of Concurrent Connections: 256
FXP supported
Passive FTP port range control
FTP bandwidth and connection control
Unicode support
Backup Server Remote Replication server (over Rsync)
Real-Time Remote Replication to another QNAP NAS or FTP server
Apple Time Machine support
Windows Client Backup Application: QNAP NetBak replicator
Third Party Backup Software Support: Acronis True Image, CA BrightStor, ARCserve, Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper and more
Web Server HTTP/HTTPS connections
Supports WebDAV connection
Support virtual host (Max.: 32)
Importable SSL certificate
Database Server Built-in MySQL server (v5.1.36)
Web-based management via phpMyAdmin (QPKG)
Print Server Max. Number of Printers: 3
Supports Internet printing protocol
-Print job display and management
-IP- and domain name based privilege control
Supports Apple bonjour printing
Syslog Server Centralized log monitoring and archiving
Immediate email alerts
Supports log filtering
RADIUS Server Centralized account management and authentication for network access
Supports 802.1x security authentication
TFTP server with PXE booting (read-only)
VPN Server Secure Remote Access: PPTP and OpenVPN services
Remote access to other resources on local network
Max. No. of Clients: 30
iTunes Server Audio and video sharing (AIF, M4A, M4B, M4V, MOV, MP1, MP2, MP3, MP4, MPEG, MPG, WAV)
Smart playlist for iTunes client (Windows and Mac OS)
UPnP Media Server Built-in TwonkyMedia server
Real-time and background photo transcoding
Supports UPnP media player such as PlayStation 3 and Xbox 360
Supported format (The actual playback capabilities may vary depending on the UPnP client.)
-Audio: MP3, MP4, M4A, M4A (ALAC), M4B, 3GP, APL, AC3, M1V, M4V, MOV, AAC, AMR, AWB, WAV, PCM, LPCM, MP1, MP2, AIF, AIFF, AIFC, SND, WMA, OGG, FLAC
-Photo: JPG, JPE, JPEG, TIFF, TIF, GIF, PNG, BMP
-Video: WMV, ASF, VDR, AVI, XVID, DIVX, FLV, MPG, MPE, MTS, M2TS, M2T, MPEG, SPTS, M2P, M2V, MP2T, MP2P, MPG2, DVR-MS, VOB
-Playlist: M3U, M3U8, WPL, PLS
Multimedia Station Supports photo, audio and video
Image slideshow and rotation
Automatic and scheduled thumbnail generation for easy browsing
Display Photo Details from EXIF: Date, exposure time, aperture and more
Display Audio Details from ID3 Tag: Album cover, title, artist, album and more
Access authority management
Multimedia (video and audio) streaming
Supports cooliris
Supports web publishing (Facebook, MySpace, MSN Live, Twitter, Plurk and Blogger)
Share photos by email
Supported Formats:
Photo – JPG/JPEG, GIF, PNG
Audio – MP3
Video
-Playback: FLV, MPEG-4 Video (H.264 + AAC)
-Transcode: AVI, M4V, MPG/MPEG, RM/RMVB, WMV
QNAP Exclusive iPhone and Android App: QMobile
Photo Station Supported File Formats:
-Photo: JPG/JPEG, GIF, PNG, BMP
-Video: FLV, MPEG-4 Video (H.264 + AAC)
Image slideshow with background music
Photo publishing to social websites (Facebook, MySpace, Twitter, Plurk and Blogger)
Photo sharing by email
Music Station Supported Audio Formats:
-MP3, MP4, OGG, WAV, AIFF, AU, FLAC, M4A, APE, AAC
Local playback with USB speaker or sound card
Browse other UPnP media servers on local network
Internet radio (MP3)
Music alarm (up to 8 Alarms)
Playback control by QNAP Mobile App: QMobile music remote
Download Station PC-less BT, FTP, HTTP download (up to 500 tasks)
BT Download
-Supports TCP/UDP tracker protocol
-Scheduled download
-Configurable port range
-Bandwidth control
-UPnP NAT port forwarding
-RSS subscription and download (broadcatching)
-Selectable download files
HTTP/ FTP Download
-Configurable saving directory
-Bulk download with wildcard settings
-RapidShare download support
QNAP Download Management Software: QGet
-For both Windows and Mac OS
-Manage the download tasks of multiple QNAP NAS remotely over LAN or WAN
Surveillance Station Supports 4 IP cameras (sold separately) for network surveillance
Supports 1 Webcam via QPKG Add-on: QUSB Cam
Antivirus Protection against the latest known viruses, trojans and other threats
Free virus databases update on manual or scheduled basis
Multiple scan tasks (max: 64, concurrent: 5) with custom folder selection and scheduled
Scanning
Email notification upon task completion or virus detection
Quarantines or deletes infected files
QPKG Center Expands application services by easy online installation
A wide variety of official and community QPKG* add-ons
Business
-eyeOS
-GLPI
-Squid proxy server
-Vtiger CRM
CMS
-Gallery
-Joomla
-WordPress
-Xoops
Communications
-Asterisk
-XMail
-Xeams
Download
-MLDonkey
-NZBGet
-pyLoad
-SABnzbdplus
-Transmission
Entertainment
-Ice Station
-Plex media server
-PS3 media server
-Squeezebox server
Utilities
-AjaXplorer
-iStat
-Optware IPKG
-phpMyAdmin
-Piwik
Miscellaneous
-Java runtime environment
-Mono
-Python
-QUSB Cam
-Tomcat and more
General
Temperature 32 to 104°F (0 to 40°C)
Relative Humidity 0 to 90%
Dimensions 8.56 x 12.8 x 12.65″ (217.42 x 325.11 x 321.3 mm)
Weight 21.67 lb (9.82 kg)
