Meraki MX68W Dubai



Meraki MX68W Dubai

The Meraki MX68W Dubai has a comprehensive suite of network services, eliminating the need for multiple appliances. These services include SD-WAN capabilities, application-based firewalling, content filtering, web search filtering,etc.

Description

Meraki MX68W Security Appliance Dubai

The Meraki MX68W Dubai is ideal for organizations considering a Unified Threat Management (UTM) solution, for distributed sites, campuses or datacenter VPN concentration. Since the MX68W is 100% cloud managed, installation and remote management are simple. The Meraki MX68W Dubai has a comprehensive suite of network services, eliminating the need for multiple appliances. These services include SD-WAN capabilities, application-based firewalling, content filtering, web search filtering, SNORT® based intrusion detection and prevention, Advanced Malware Protection (AMP), web caching, 4G cellular failover and more. Auto VPN and SD-WAN features are available on our hardware and virtual appliances, configurable in Amazon Web Services or Microsoft Azure.

Meraki MX68W Key Features

  • Application-aware traffic control: bandwidth policies for Layer 7 application types (e.g., block YouTube, prioritize Skype, throttle BitTorrent)
  • Content filtering: CIPA-compliant content filter, safe-search enforcement (Google/Bing), and YouTube for Schools
  • Intrusion prevention: PCI-compliant IPS sensor using industry-leading SNORT® signature database from Cisco
  • Advanced Malware Protection: file reputation-based protection engine powered by Cisco AMP
  • Identity-based security policies and application management

Technical Specifications

General

  • Recommended Use Cases : Small branch
  • Recommended Clients : 50
  • Stateful Firewall Throughput : 450 Mbps
  • Advanced Security Throughput : 300 Mbps
  • Maximum VPN Throughput : 200 Mbps
  • Maximum Concurrent VPN Tunnels : 50
  • WAN Interfaces ( Dedicated) : 2 x GbE RJ45, 1 x USB (cellular failover )
  • LAN Interfaces : Fixed 10 x GbE RJ45, ( 2 x PoE+)
  • Mounting : Desktop or wall mount
  • Dimensions : 11.2” x 6.8” x 1.1” (284mm x 148mm x 27mm)
  • Weight : 2.55 lb (1.16 kg)
  • Power Supply : 100W DC
  • Operating Temperature : 32°F to 104°F (0°C to 40°C)
  • Humidity : 5% to 95%

Management

  • Managed via the web using the Cisco Meraki dashboard
  • Single-pane-of-glass into managing wired and wireless networks
  • Zero-touch remote deployment (no staging needed)
  • Automatic firmware upgrades and security patches
  • Templates based multi-network management
  • Org-level two-factor authentication and single sign-on
  • Role-based administration with change logging and alerts

Monitoring and Reporting

  • Throughput, connectivity monitoring and email alerts
  • Detailed historical per-port and per-client usage statistics
  • Application usage statistics
  • Org-level change logs for compliance and change management
  • VPN tunnel and latency monitoring
  • Network asset discovery and user identification
  • Periodic emails with key utilisation metrics
  • Device performance and utilisation reporting
  • Netflow support
  • Syslog integration

Remote Diagnostics

  • Live remote packet capture
  • Real-time diagnostic and troubleshooting tools
  • Aggregated event logs with instant search

Network and Firewall Services

  • Stateful firewall, 1:1 NAT, DMZ
  • Identity-based policies
  • Auto VPN: Automated site-to-site (IPsec) VPN, for hub-and-spoke or mesh topologies
  • Client (IPsec L2TP) VPN
  • Multiple WAN IP, PPPoE, NAT
  • VLAN support and DHCP services
  • Static routing
  • User and device quarantine

WAN Performance Management

  • Web caching (available on the MX84, MX100, MX250, MX450)
  • WAN link aggregation
  • Automatic Layer 3 failover (including VPN connections)
  • 3G / 4G USB modem failover or single-uplink
  • Application level (Layer 7) traffic analysis and shaping
  • Ability to choose WAN uplink based on traffic type
  • SD-WAN : Dual active VPN with policy-based routing and dynamic path selection
  • CAT 6 LTE modem for failover or single-uplink1

Advanced Security Services

  • Content filtering (Webroot BrightCloud CIPA compliant URL database)
  • Web search filtering (including Google / Bing SafeSearch)
  • YouTube for Schools
  • Intrusion-prevention sensor (Cisco SNORT® based)
  • Advanced Malware Protection (AMP)
  • AMP Threat Grid
  • Geography-based firewall rules (MaxMind Geo-IP database)

Integrated Cellular

  • LTE bands : 2, 4, 5, 12, 13, 17, and 19 (North America). 1, 3, 5, 7, 8, 20, 26, 28A, 28B, 34, 38, 39, 40, and 41 (Worldwide)
  • 300 Mbps CAT 6 LTE
  • Additional regulatory information : PTCRB (US), RCM (ANZ, APAC), GCF (EU)

Regulatory

  • FCC (US)
  • CB (IEC)
  • CISPR (Australia/New Zealand)
  • PTCRB (US)
  • RCM (Australia/New Zealand, Asia Pacific)
  • GCF (EU)

Warranty

  • Full lifetime hardware warranty with next-day advanced replacement included.
