DESCRIPTION TO Hanwha XNV-6080 CCTV Camera
The Hanwha XNV-6080 is a professional-grade 2MP outdoor vandal-resistant IR dome CCTV camera, engineered for long-term performance in harsh UAE environments. As part of the Hanwha Wisenet X series — formerly Samsung CCTV — it combines full HD video quality, robust housing, and smart analytics in one rugged, weatherproof surveillance device.
2MP Clarity with Motorized Zoom
The Hanwha XNV-6080 is a professional-grade 2MP outdoor vandal-resistant IR dome CCTV camera, engineered for long-term performance in harsh UAE environments. As part of the Hanwha Wisenet X series — formerly Samsung CCTV — it combines full HD video quality,
WiseIR for Night Vision
Hanwha XNV-6080 advanced features like 150dB Wide Dynamic Range (WDR), WiseNR II, Defog, and motion analytics make this camera ideal for both proactive and reactive surveillance. With WiseStream II compression and H.265 support, it ensures efficient use of bandwidth and storage — a perfect fit for enterprise and city-wide security projects.
Rugged Outdoor Protection with Full HD Precision
The Hanwha XNV-6080 is engineered for outdoor environments where surveillance demands high durability and consistent high-resolution video. Whether it’s a shopping center parking area in Dubai, perimeter monitoring at an airport, or a government facility entrance in Abu Dhabi, this Hanwha XNV-6080 camera delivers professional-grade protection and performance.
Technical Specifications
Video & Optics
- Image Sensor: 1/2.8” 2MP CMOS
- Max Resolution: 1920 x 1080 (Full HD)
- Frame Rate: 60fps @ Full HD
- WDR: 150dB
- Lens: 2.8 – 12mm motorized varifocal
- Field of View:
- Horizontal: 111.2° ~ 32.0°
- Vertical: 60.0° ~ 18.2°
- Minimum Illumination:
- Color: 0.015 Lux (F1.4)
- B/W: 0 Lux (IR ON)
Infrared & Night Surveillance
- IR Distance: Up to 50 meters
- IR Control: Smart IR for brightness balance
- True Day/Night: Yes (ICR)
Compression & Streaming
- Codecs: H.265, H.264, MJPEG
- Smart Compression: WiseStream II
- Streaming: Triple streaming
- Edge Storage: microSD/SDHC/SDXC up to 512GB
Audio, Network & Integration
- Audio: Bi-directional with built-in mic support
- Network Protocols: IPv4/IPv6, HTTPS, SSL, RTSP, NTP, SNMP
- ONVIF: Profiles S, G, T
- Power: 12VDC or PoE (IEEE 802.3af Class 3)
- Operating Temp: -40°C ~ +55°C
- IK Rating: IK10 (vandal-resistant)
- Ingress Protection: IP66 / IP67 / NEMA 4X
- Housing Material: Aluminum die-cast
- Dimensions: Ø155.0 x 129.0 mm
Specifications
| Video | |
| Imaging Device | 1/2.8″ 2MP CMOS |
| Effective Pixels | 1945(H)x1109(V) |
| NETD | None |
| Pixel Size | None |
| Min. Illumination | Color: 0.015 lux(F1.4, 1./30sec) B/W: 0.015 lux(F1.4, 1./30sec) |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P), for installation USB: Micro USB Type B, 1280×720, for installation |
| Lens | |
| Focal Length (Zoom Ratio) | 2.8~12mm(4.3x) motorized varifocal |
| Max. Aperture Ratio | F1.4(Wide) ~ F3.6(Tele) |
| Angular Field of View | H: 119.5°(Wide)~27.9°(Tele), V: 62.8°(Wide)~15.7°(Tele), T: 142.1°(Wide)~32.0°(Tele) |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Simple remote control focus via network |
| Lens Type | DC auto iris, P iris |
| Mount Type | None |
| Optional Lens | None |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Range | 0˚~354˚ / 0˚~67˚ / 0˚~355˚ |
| Pan Range | None |
| Pan Speed | None |
| Tilt Range | None |
| Tilt Speed | None |
| Rotate Range | None |
| Sequence | None |
| Preset Accuracy | None |
| Azimuth | None |
| Auto Tracking | None |
| Operational | |
| IR Viewable Length | None |
| Camera Title | Displayed up to 85 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, WDR, DWDR, SSDR |
| Wide Dynamic Range | 150dB |
| Digital Noise Reduction | SSNRⅤ |
| Digital Image Stabilization | Support |
| Defog | Support |
| Motion Detection | 8ea, 8point polygonal zones |
| Privacy Masking | 32ea, polygonal zones – Color: Grey/Green/Red/Blue/Black/White – Mosaic |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| LDC | Support |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Digital PTZ | Support |
| Video Rotation | Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics | Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification |
| Business Intelligence | Not support |
| Serial Interface | Not support |
| Alarm I/O | Input 1ea / Output 1ea |
| Alarm Triggers | Analytics, Network disconnect, Alarm input |
| Alarm Events | File upload via FTP and E-Mail Notification via E-Mail SD/SDHC/SDXC or NAS recording at Event Triggers Alarm output Handover |
| Audio In | Selectable(Mic in/Line in), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out | Line out, Max. output level: 1Vrms |
| IR Illuminator (Optional) | None |
| Wiper | None |
| Coaxial Protocol | None |
| Video Transmission Distance | None |
| Radiometry | |
| Temperature detect range | None |
| Temperature accuracy | None |
| Temperature detection | None |
| Additional | None |
| Network | |
| Ethernet | RJ-45(10/100BASE-T) |
| Video Compression | H.265/H.264: Main/Baseline/High, MJPEG |
| Resolution | 1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate | H.265/H.264 : Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| Smart Codec | Manual(5ea area) WiseStreamⅡ |
| Video Quality Adjustment | H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming | Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
| Audio Compression | G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC : 48Kbps at 16KHz |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour , LLDP, SRTP(Unicast) |
| Security | HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access Log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage | Micro SD/SDHC/SDXC 2slot 512GB |
| Application Programming Interface | ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
| Webpage Language | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer | Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Recommended Browser: Google Chrome Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory | 1024MB RAM, 256MB Flash |
| Environmental | |
| Operating Temperature / Humidity | -40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity | -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification | IP67/IP66/NEMA4X, IK10 |
| Electrical | |
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC, 24VAC |
| Power Consumption | PoE: Max 7.8W 12VDC: Max 7W 24VAC: Max 8.2W |
| Mechanical | |
| Color / Material | Ivory / Aluminum |
| RAL Code | None |
| Product dimension / weight | Ø160xH118.5mm (Ø6.3×4.67″), 985g(2.17 lb) |
| Conduit hole | None |
| Hanging mount(Dome) | None |
| Skin cover(Dome) | None |
| Weather cap(Dome) | None |
| Power module | None |
| Backbox | None |
