Hanwha XNO-8080R CCTV camera, previously recognized under Samsung CCTV branding, is a robust outdoor bullet camera offering unmatched image clarity and advanced surveillance capabilities for deployments in Dubai, Abu Dhabi, and across the UAE

Description

DESCRIPTION TO Hanwha XNO-8080R CCTV Camera

The Hanwha XNO-8080R CCTV camera, previously recognized under Samsung CCTV branding, is a robust outdoor bullet camera offering unmatched image clarity and advanced surveillance capabilities for deployments in Dubai, Abu Dhabi, and across the UAE. Designed for high-risk environments, it combines 5MP resolution, long-range IR coverage, and advanced WDR to deliver detailed imagery even in dynamic lighting.

High-Resolution Performance

The Hanwha XNO-8080R delivers crisp 5MP resolution (2560×1920) for wide-area surveillance with forensic-level clarity—suitable for license plate monitoring, public security, and infrastructure protection.

Durable and Weatherproof

Its IP66/IK10 housing ensures outdoor resilience, making it perfect for use in dusty, rainy, or vandal-prone locations.

Smart Infrared Illumination

Built-in IR LED technology provides up to 50 meters of night visibility, ensuring reliable video capture in total darkness with automatic IR intensity control.

Intelligent Video Analytics

Advanced analytics include motion detection, virtual line crossing, loitering detection, and face detection—vital for proactive monitoring.

Streamlined Storage

WiseStream II and H.265 deliver bandwidth-efficient streaming while maintaining quality. It also supports edge recording via microSD card (up to 512GB).

Fast Integration & Setup

Thanks to ONVIF compatibility, the XNO-8080R is easily configured into new or existing systems with minimal effort.

Ideal for Critical Security Zones

This camera is well-suited for airports, logistics yards, factories, and government premises where performance, durability, and intelligence are mandatory.

Authorized Hanwha Distributor in Dubai

Always purchase from an official Hanwha Distributor in Dubai to ensure warranty support, technical assistance, and authentic equipment delivery.

Related Surveillance Solutions

For a complete security system, combine the XNO-8080R with cameras like the XND-6081REV and XNF-9010RS to create seamless multi-zone monitoring.

Key Specification

  • Imaging Device: 1/1.8″ 5MP CMOS sensor
  • Resolution: 5MP (2560×1920) @ up to 30fps
  • Lens: 4.44~142.6mm motorized varifocal lens
  • IR Distance: Up to 50m (WiseIR)
  • Minimum Illumination: Color: 0.05 Lux; B/W: 0 Lux (IR ON)
  • WDR: 150dB
  • Compression: H.265, H.264, MJPEG with WiseStream II
  • Storage: microSD/SDHC/SDXC (up to 512GB)
  • Analytics: Motion, tampering, line crossing, face detection, loitering
  • Power: PoE (IEEE802.3af), 12V DC; Max 13W
  • Connectivity: RJ-45 (10/100BASE-T)
  • Audio: 1 input / 1 output, two-way audio
  • Environmental Ratings: IP66, IK10
  • Operating Temperature: -30°C to +55°C
  • Dimensions: 91.7 x 83.4 x 256.1 mm
  • Weight: 1.1kg

Specification

Video
Imaging Device 1/1.8″ 6MP CMOS
Resolution 2560×1920, 2560×1440, 1920×1080, 1600×1200, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240
Max. Framerate H.265/H.264 : Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination Color: 0.07Lux(F1.3, 1/30sec, 30IRE)
BW: 0.007Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on)
Video Out CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P), for installation
USB: Micro USB Type B, 1280×720, for installation
Lens
Focal Length (Zoom Ratio) 3.7~9.4mm(2.5x) motorized varifocal
Max. Aperture Ratio F1.2
Angular Field of View H: 100.2°(Wide)~38.7°(Tele)
V: 72.2°(Wide)~29.0°(Tele)
D: 132.0°(Wide)~48.6°(Tele)
Min. Object Distance 0.5m(1.64ft)
Focus Control Simple focus
Lens Type DC auto iris, P iris(IR corrected)
Operational
Camera Title Displayed up to 85 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR, DWDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅤ
Digital Image Stabilization Support
Defog Support
Motion Detection 8ea, 8point Polygonal zones
Privacy Masking 32ea, Quadrangle zones
– Color : Gray, Green, Red, Blue, Black, White
– Mosaic
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation Flip, Mirror, Hallway view(90°/270°)
Analytics Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification
Alarm I/O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events When alarm trigger occurred
– File upload(image) : e-mail/FTP
– Notification : e-mail
– Recording : SD/SDHC/SDXC or NAS recording at event triggers
– Alarm output
– Handover
Audio In Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out Line out, Max.output level: 1Vrms
IR Viewable Length 50m(164.04ft)
Network
Ethernet RJ-45(10/100BASE-T)
Video Compression H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz
Smart Codec Manual(5ea area), WiseStreamⅡ
Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBR
Streaming Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles)
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access Log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform
General
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian
Edge Storage Micro SD/SDHC/SDXC 2slot 512GB
Memory 1024MB RAM, 256MB Flash
Environmental & Electrical
Operating Temperature / Humidity -40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification IP67/IP66/NEMA4X, IK10
Input Voltage PoE(IEEE802.3af, Class3), 12VDC, 24VAC
Power Consumption PoE: Max 12.95W
12VDC: Max 12.5W
24VAC: Max 14.5W
Mechanical
Color / Material Dark grey / Aluminum
Product Dimensions / Weight Ø91×368.6mm(Ø6.3×4.67″), 2180g(4.8 lb)
