The Flyingvoice FWR9601 VoIP Wireless Router pushes versatility to a new high, thanks to its ability to complement already existing fixtures for enhanced web and audio conferencing, as well as other communication needs.

Category:

Description

Flyingvoice FWR9601 VoIP Wireless Router Dubai

Flyingvoice FWR9601 Dubai VoIP Router integrates internet sharing for daily application, making it the best choice for any VoIP communication. It not only provides for high quality voice communications, but also offers Access Point (AP) function to meet your daily wireless communication needs. FWR9601 VoIP Router is SIP v2.0 – based, enabling you to make calls via Proxy voice communications, IP sharing, as well as the QoS mechanism. It meets the 802.11n wireless standards and is fully compatible with most internet service providers.

The Flyingvoice FWR9601 Dubai has 1 FXS telephone port and 5 10/100Mbps Ethernet ports which are greatly convenient when deploying VoIP networks. You can use your FWR9601 VoIP Router as an FTP server to share LAN files, pictures and other media, making it ideally suitable for small and medium enterprises.

Top Features:

  • 1 FXS Port
    • Foreign Exchange Subscribers is the port that actually delivers the analog line to the subscriber. it is simply the “plug in the wall” that delivers a dial tone, battery current and ring voltage. This is the jack or interface to the phone system which FXO devices can be connected to. The Flyingvoice FWR9601 Dubai Wireless VoIP Router has been equipped with 1 FXS port to maximize communication while using your telephone to make calls, thus maximizing work productivity.
  • Firmware Upgradeable
    • You can easily update the operating system on your Flyingvoice FWR9601 Dubai VoIP Wireless Router so as to improve its functionality and enhance user experience. Upgrading firmware also fixes any existing bugs and protects you from any kind of software malfunctions and  vulnerabilities. To update your router’s firmware, type your router’s IP address into your web browser and enter your login information. Then locate the Firmware or Update section and download the latest firmware update on your router manufacturer’s website. Finally, upload the update and reboot the router.
  • Rich Layer 2 / 3 QoS Capabilities
    • Quality of Service (QoS) is a feature of routers and switches which prioritizes traffic so that more important traffic can pass first, resulting in an overall performance improvement for critical network traffic. This feature is very useful in the Flyingvoice FWR9601 Dubai VoIP Wireless Router whenever there are high volumes of traffic, therefore eliminating any delays while working.
  • High Flexibility
    • The Flyingvoice FWR9601 VoIP Wireless Router pushes versatility to a new high, thanks to its ability to complement already existing fixtures for enhanced web and audio conferencing, as well as other communication needs. This makes it easy to integrate seamlessly into any office setup without disorienting earlier structures and work ethic. Furthermore, the device is easy to redeploy as the business grows and needs to transform.
  • Outstanding Audio Clarity
    • The Flyingvoice FWR9601 Dubai VoIP Wireless Router offers users distraction-free communication courtesy of the inbuilt industry-leading Acoustic Echo Cancelling Technology,  Adaptive Jitter Buffer, Voice Activity Detection, and Comfort Noise Generation that deliver superior High Definition sound quality devoid of extraneous noises. This makes it possible to enjoy fluent phone conversations.

FWR9601 – Technical Specs

Chipset Solution : MT7621A,MT7612E,MT7603E

RAM : 64MB DDR RAM

Flash : 16MB Flash

Operating System: Linux

Audio Codec :

  • G.711 (A/u), PAMS>4.3
  • G.729A/AB, PAMS>3.7
  • T.30 FAX with G.711
  • Real time FAX over IP via T.38
  • Adaptive Jitter Buffer
  • Voice Activity Detection
  • Comfort Noise Generation
  • Echo Cancellation

Power :

  • AC/DC Adapter :

AC Input: 100~240V, 50~60Hz

DC Output: 12V, 1A

I/O Interfaces :

  • 1 RJ-45 for WAN port (Ethernet 1000 Base-T)
  • 4 RJ-45 for LAN port (Ethernet 1000 Base-T)
  • 1 RJ-11 for FXS port
  • Two 5dBi Antenna for IEEE802.11n 2T2R Wireless

Environmental

  • Operation Temperature: 0~50 Degree C
  • Storage Temperature: -25~85 Degree C
  • Relative Humidity: 10%~90% Non Condensing

Protocols

  • SIP V2.0 (RFC 3261, 3262, 3263, 3264)
  • SDP (RFC2327)
  • RTP/RTCP (RFC823/903)
  • NAPTR for SIP URI lookup (RFC2915)
  • STUN (RFC2030)
  • ARP/RARP (RFC 826/903)
  • SNTP (RFC 2030)
  • DHCP/PPPoE
  • HTTP Server for Web Management
  • TFTP/HTTP for Auto Provisioning
  • Message Waiting Indicator (RFC3842)
  • DHCP Option Codes for SIP (RFC3361)
  • DNS/DNS SRV (RFC1706 and RFC 2782)
  • IEEE802.1Q VLAN/802.1p and IP DSCP
  • IEEE 802.11a/b/g/n/ and 802.11ac Wave 2

Management :

  • Firmware Upgradeable
  • Web Management Interface
  • IVR-driven Management Interface
  • Local and Remote Syslog (RFC3164)
  • Auto Provisioning
  • SNTP Time Synchronization
  • Multi User Level
  • SNMPv2
  • TR069
  • Telnet
  • System Log: local log and remote log

Call Features

  • 3-way conference
  • Call hold
  • Call forwarding
  • Call Transfer
  • Call waiting
  • Caller ID and CWCID
  • DTMF mode: In-band, RFC2833 and SIP INFO
  • QoS Layer 2/3
  • Call Log
  • CID/CWCID
  • Dial Plan
  • DTMF Mode: Inband, out band and SIP Info

Applications :

  • Support NAT mode and Bridge mode
  • Support DDNS
  • MAC address cloning
  • SIP proxy redundancy
  • NAT Traversal by STUN
  • Built-in Wired speed NAT Router
  • DHCP Server and Client
  • IP conflict detection
  • VLAN
  • Flow Control
  • VPN Pass through (PPTP,L2TP and IPSec)
  • SNTP
  • 802.1Q VLAN/802.1p, DSCP, Rate Limiting
  • IGMPv2, IGMPv3
  • ACL (Access Control List)
  • Broadcast Storm Control
  • Mac Filtering
  • Firewall (SYN Flooding, IP Spoofing, Smurf Attack, Ping of Death, DoS)
  • Ipv6 (Dual Stack)
  • MLDv1, MLDv2

Wireless :

  • TX Power :
    • 15dBm @ 2.4GHz 11n MCS7 HT40M
    • 15dBm @ 5GHz 11ac MCS9 VHT80M
  • RX Sensitive :
    • 70dBm @ 2.4GHz 11n MCS7 HT40
    • -53dBm @ 5GHz 11ac MCS9 VHT80
  • 4 SSID Per Radio
  • Static WEP (64/128bit)
  • Dynamic WEP (64/128bit)
  • AES (CCMP/TKIP)

 MAC certification

  • WEP certification
  • WPA-PAK/WPA-PSK (2.0)
  • WPA/WPA2
  • AP Isolation and MBSSID AP Isolation
  • WMM
  • WDS
  • WPS
  • Station list
  • Wireless MAC Filter

Certificates :

  • FCC Part 15 Class B approval
  • CE certification

WARRANTY INFORMATION

The Flyingvoice FWR9601 Wireless VoIP Router comes with a one – year limited warranty.
