DESCRIPTION TO Hanwha XNV-6120 CCTV Camera
The Hanwha XNV-6120 is designed for tough outdoor surveillance environments where video clarity, physical protection, and 24/7 monitoring are mission-critical. This camera thrives in public-facing installations — from municipal buildings in Sharjah to resort entrances in Ras Al Khaimah — providing Full HD visibility day and night.
2MP Clarity with night vision
The Hanwha XNV-6120 CCTV Camera is a professional-grade 2MP outdoor IR dome CCTV camera built with IK10 vandal resistance and IP66 weatherproof housing — making it ideal for harsh environments across Dubai, Abu Dhabi, and the UAE. Whether installed in public zones, perimeter walls, or outdoor entry points, it delivers Full HD 1080p resolution with powerful infrared night vision and smart surveillance capabilities.
WiseIR for X SERIES
The Hanwha XNV-6120 Part of the trusted Wisenet X series, the Hanwha XNV-6120 features a 1/2.8″ CMOS sensor and supports 60fps at 2MP resolution for ultra-smooth, high-clarity video. The 2.8–12mm motorized varifocal lens allows flexible field of view adjustment during installation or remotely via VMS/NVR, minimizing setup time.
Rugged and Smart Outdoor Surveillance
The Hanwha XNV-6120 is designed for tough outdoor surveillance environments where video clarity, physical protection, and 24/7 monitoring are mission-critical. This camera thrives in public-facing installations — from municipal buildings in Sharjah to resort entrances in Ras Al Khaimah — providing Full HD visibility day and night.
KeySpecifications
Video & Imaging
- Sensor: 1/2.8” 2MP CMOS
- Resolution: 1920 x 1080 (Full HD)
- Max Frame Rate: 60fps @ 1080p
- WDR: 150dB
- Minimum Illumination:
- Color: 0.015 Lux (F1.4, 1/30sec)
- B/W: 0 Lux (IR ON)
- Digital Noise Reduction: WiseNR II
- Day/Night: True Day/Night (ICR)
Lens & Field of View
- Lens Type: Motorized Varifocal
- Focal Length: 2.8 – 12mm
- Field of View:
- Horizontal: 111.2° ~ 32.0°
- Vertical: 60.0° ~ 18.2°
IR & Night Vision
- IR Range: Up to 50 meters
- Smart IR: Yes
Specifications
Video | |
Imaging Device | 1/2.8″ CMOS |
Resolution | 1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
Max. Framerate | H.265/H.264: Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
NETD | None |
Pixel Size | None |
Min. Illumination | Color: 0.03Lux(F1.6, 1/30sec) BW: 0.003Lux(F1.6, 1/30sec) |
Video Out | CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation USB: Micro USB Type B, 1280×720 for installation |
Video Transmission Distance | None |
Lens | |
Focal Length (Zoom Ratio) | 5.2~62.4mm(12x) zoom |
Max. Aperture Ratio | F1.6(Wide)~F3.0(Tele) |
Angular Field of View | H: 54.58°(Wide)~5.30°(Tele) V: 32.19°(Wide)~3.00°(Tele) D: 61.4(Wide)~6.06(Tele) |
Min. Object Distance | 2.1m(6.89ft) |
Focus Control | Oneshot AF |
Lens Type | DC auto iris |
Mount Type | None |
Optional Lens | None |
Pan / Tilt / Rotate | |
Pan / Tilt / Rotate Range | 0˚~354˚ / 0˚~75˚ / 0˚~355˚ |
Pan Range | None |
Pan Speed | None |
Tilt Range | None |
Tilt Speed | None |
Rotate Range | None |
Sequence | None |
Preset Accuracy | None |
Operational | |
Camera Title | Displayed up to 85 characters |
Direction Indicator | None |
Day & Night | Auto(ICR) |
Backlight Compensation | BLC, HLC, WDR, SSDR |
Wide Dynamic Range | 150dB |
Digital Noise Reduction | SSNRⅤ |
Digital Image Stabilization | Support |
Defog | Support |
Motion Detection | 8ea, 8point Polygonal zones |
Privacy Masking | 32ea, Quadrangle zones – Color : Gray, Green, Red, Blue, Black, White – Mosaic |
Gain Control | Low / Middle / High |
White Balance | ATW / AWC / Manual / Indoor / Outdoor |
LDC | Support |
Electronic Shutter Speed | Minimum / Maximum / Anti flicker (2~1/12,000sec) |
Digital PTZ | None |
Video Rotation | Flip, Mirror, Hallway view(90°/270°) |
Analytics | Analytics events – Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification |
Business Intelligence | None |
Serial Interface | None |
Alarm I/O | Input 1ea / Output 1ea |
Alarm Triggers | Analytics, Network disconnect, Alarm input |
Alarm Events | When alarm trigger occurred – File upload(image) : e-mail/FTP – Notification : e-mail – Recording : SD/SDHC/SDXC or NAS recording at event triggers – Alarm output – Handover(PTZ preset) |
Audio In | Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out | Line out, Max.output level: 1Vrms |
IR Viewable Length | None |
IR Illuminator (Optional) | None |
Water Removal | None |
Auto Tracking | None |
Coaxial Protocol | None |
Color Palettes | None |
Radiometry | |
Temperature Detect Range | None |
Temperature Accuracy | None |
Temperature Detection | None |
Additional | None |
Network | |
Ethernet | RJ-45(10/100BASE-T) |
Video Compression | H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression | G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec | Manual(5ea area), WiseStreamⅡ |
Video Quality Adjustment | H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming | Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
Security | HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
Application Programming Interface | ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General | |
Webpage Language | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
Web Viewer | None |
Edge Storage | Micro SD/SDHC/SDXC 2slot 512GB |
Memory | 1024MB RAM, 256MB Flash |
Environmental & Electrical | |
Operating Temperature / Humidity | -40°C~+55°C(-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -35°C |
Storage Temperature / Humidity | -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification | IP66/IP67, IK10, NEMA 4X |
Input Voltage | PoE(IEEE802.3af, Class3), 12VDC, 24VAC |
Power Consumption | PoE : Max 7.8W 12VDC : Max. 7W 24VAC : Max. 8.2W |
Mechanical | |
Color / Material | Ivory / Aluminum |
RAL Code | None |
Product Dimensions / Weight | Ø160×128.5mm(6.30″x5.06″), 985g(2.17 lb) |
Compatible Conduit hole / Gangbox | None |
Hanging Mount (Dome) | SBP-300HM6 |
Skin Cover (Dome) | None |
Weather Cap (Dome) | None |
Power Module | None |
Backbox | None |
DORI (EN62676-4 standard) | |
Detect (25PPM/ 8PPF) | Wide: 74.4m(572.64ft) / Tele: 829.7m(2,721.97ft) |
Observe (63PPM/ 19PPF) | Wide: 29.8m(97.68ft) / Tele: 331.9m(1,088.79ft) |
Recognize (125PPM/ 38PPF) | Wide: 14.9m(48.84ft) / Tele: 165.9m(544.39ft) |
Identify (250PPM/ 76PPF) | Wide: 7.4m(24.4ft) / Tele: 83.0m(272.2ft) |
