Description
Cisco WAP131 Access Point Dubai
The Cisco WAP131 Dubai is a Wireless-N Dual Radio Access Point which has been designed to provide a simple, cost-effective way to extend secure, high-performance mobile networking to your employees and guests, so they can stay connected anywhere in the office. It simply enables you to connect dozens of employees, and can scale to accommodate additional users and changing business needs.
Cisco WAP131 Dubai uses concurrent dual-band radios for improved coverage and user capacity. The Gigabit Ethernet port allows the AP to be powered by PoE switch to help reduce cabling and wiring costs. Intelligent quality-of-service (QoS) features let you prioritize bandwidth-sensitive traffic for voice‑over-IP (VoIP) and video applications.
Cisco Wi-Fi Dubai is easy to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. An attractive desktop design with an integrated stand allows you to place the AP on your desk vertically or horizontally.
To enhance reliability and safeguard sensitive business information, the Cisco WAP131 Dubai Wireless-N Dual Radio Access Point supports both Wi-Fi Protected Access (WPA) Personal and Enterprise, encoding all your wireless transmissions with powerful encryption. In addition, 802.1 X RADIUS authentications help keep unauthorized users out.
Features
- Cisco WAP131 Dubai offers concurrent dual-band radio support for up to 300 Mbps per radio to maximize capacity and coverage.
- Cisco Wi-Fi Dubai is equipped with a single Gigabit Ethernet LAN interface which enables a high-speed uplink to the wired network.
- Cisco WAP131 Dubai offers robust security, including WPA2, 802.1X with RADIUS secure authentication, and rogue-access-point detection, helps protect sensitive business information.
- Simple installation and intuitive web-based configuration and wizard enable fast, simple deployment and setup in minutes.
- Cisco Wi-Fi Dubai boasts of a simple, desktop design with integrated stand, for easy access and placement.
- Intelligent QoS prioritizes network traffic to help keep critical network applications running at top performance.
- Cisco WAP131 Dubai has power-saving sleep mode and port control features which help maximize energy efficiency.
- Workgroup Bridge mode lets you expand your network by wirelessly connecting to a second Ethernet network.
- Cisco WAP131 Dubai has built-in support for IPv6 lets you deploy future networking applications and operating systems without costly upgrades.
- Limited lifetime hardware warranty provides peace of mind.
Specifications
|
Standards |
IEEE 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) |
|
|
Cabling type |
Category 5e or better |
|
|
Antennas |
Internal antennas optimized for desktop installation with vertical orientation |
|
|
LED indicators |
Power, WLAN, LAN |
|
|
Operating system |
Linux |
|
|
Physical Interfaces |
||
|
Ports |
10/100/1000 Ethernet, with support for 802.3af/at PoE, Power Port for AC adapter |
|
|
Power Supply |
External 12V 1.5A DC power jack (Energy Star 2.0 compliant with Efficiency Level 5) and 802.3af/at PoE |
|
|
Buttons |
Reset button, Power (on/off), Push button |
|
|
Lock slot |
Slot for Kensington lock |
|
|
LEDs |
Power, Wireless, Ethernet |
|
|
Physical Specifications |
||
|
Physical dimensions (W x D x H) |
6.693 x 6.693x 1.413 in. (170 x 170 x 35.9 mm) |
|
|
Weight |
0.89 lb (0.40kg) |
|
|
Network Capabilities |
||
|
VLAN support |
Yes |
|
|
Number of VLANs |
1 management VLAN plus 8 VLANs for SSIDs |
|
|
802.1X supplicant |
Yes |
|
|
SSID-to-VLAN mapping |
Yes |
|
|
Auto channel selection |
Yes |
|
|
Spanning tree |
Yes |
|
|
Load balancing |
Yes |
|
|
IPv6 |
Yes
|
|
|
Layer 2 |
802.1Q-based VLANS, 8 active VLANS plus 1 management VLAN |
|
|
Security |
||
|
WPA and WPA2 |
Yes, including Enterprise authentication |
|
|
Access control |
Yes, management access control list (ACL) plus MAC ACL |
|
|
Secure management |
HTTPS |
|
|
SSID broadcast |
Yes |
|
|
Rogue-access-point detection |
No |
|
|
Mounting and Physical Security |
||
|
Mounting options |
Desktop only |
|
|
Physical security lock |
Kensington lock slot |
|
|
Quality of Service |
||
|
Quality of service (QoS) |
Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), Client QoS |
|
|
Performance |
||
|
Wireless throughput |
Up to 300-Mbps data rate (real-world throughput will vary) |
|
|
Recommended user support |
Up to 32 connective users, 16 active users per radio |
|
|
Configuration |
||
|
Web user interface |
Built-in web user interface for easy browser-based configuration (HTTP/HTTPS) |
|
|
Management |
||
|
Management protocols |
Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour |
|
|
Remote management |
Yes |
|
|
Event logging |
Local, remote syslog, email alerts |
|
|
Network diagnostics |
Logging and packet capture |
|
|
Web firmware upgrade |
Firmware upgradable through web browser, imported/exported configuration file |
|
|
Dynamic Host Configuration Protocol (DHCP) |
DHCP client |
|
|
IPv6 host |
Yes |
|
|
HTTP redirect |
No |
|
|
Wireless |
||
|
Frequency |
Dual concurrent radios (2.4 and 5 GHz) |
|
|
Radio and modulation type |
Dual radio, orthogonal frequency division multiplexing (OFDM) |
|
|
WLAN |
|
|
|
Data rates supported |
|
|
|
Frequency Band and 20-MHz Operating Channels |
A Regulatory Domain :
|
E Regulatory Domain :
C Regulatory Domain :
|
|
Maximum Number of Non-overlapping Channels |
2.4 GHz
|
5 GHz
|
|
Wireless isolation |
Wireless isolation between clients |
|
|
External antennas |
None |
|
|
Internal antennas |
Internal Fixed PiFA Antenna |
|
|
Antenna gain in dBi |
|
|
|
Wireless distribution system (WDS) |
Yes |
|
|
802.11i |
Yes |
|
|
Multiple SSIDs |
8 |
|
|
Wireless VLAN map |
Yes |
|
|
WLAN security |
Yes |
|
|
Wi-Fi Multimedia (WMM) |
Yes, with unscheduled automatic power save |
|
|
Operating Modes |
||
|
Access point |
Access Point mode, WDS Bridging, Workgroup Bridge mode |
|
|
Environmental |
||
|
Power options |
|
|
|
Compliance |
Safety :
Radio approvals :
EMI and susceptibility (Class B) :
|
|
|
Operating temperature |
0° to 40°C (32° to 104°F) |
|
|
Storage temperature |
-20° to 70°C (-4° to 158°F) |
|
|
Operating humidity |
10% to 85% noncondensing |
|
|
Storage humidity |
5% to 90% noncondensing |
|
|
System memory |
|
|
|
Package Contents |
||
|
||
|
Minimum Requirements |
||
|
||
|
Warranty |
||
|
Access point |
Limited lifetime |
|
