Ruijie RG-EG105GV2 Router Dubai

RG-EG series realizes the industry-leading auto-discovery and auto-networking features for gateways, switches and wireless. It is a is a cloud-managed modern router that comes with a simple user interface.

Description

Ruijie RG-EG105GV2 Router Dubai

Designed for use in restaurants, villas, small offices, and hostels, the Ruijie RG-EG105GV2 Router Dubai is a cloud-managed modern router that comes with a simple user interface that requires no technical expertise. The router is affordable and is equipped with a 500M bandwidth with built-in support for up to 100 terminals.

The built-in network controller of Ruijie RG-EG105GV2 Router Dubai can centrally manage up to 32 Reyee APs and up to 128 Reyee cloud managed switches. RG-EG series realizes the industry-leading auto-discovery and auto-networking features for gateways, switches and wireless, offering unified configuration, remote management and remote fault diagnosis of the entire network via the Ruijie Cloud app.

When working on AC mode, Ruijie RG-EG105GV2 Router Dubai can centrally manage up to 300 Reyee APs and up to 128 Reyee cloud managed switches and RG-EG210G-P / RG-EG210G-E can manage up to 500 Reyee APs and up to 128 Reyee cloud managed switches.

Features:

Auto-provisioning via Self-Organizing Network : RG-EG series realizes the industry-leading auto-discovery and auto-networking features for gateways, switches and wireless;

Lifetime free Ruijie Cloud managed : Remote fault alarm, one-click operation and maintenance on Ruijie Cloud App;

Multiple WAN Ports : Up to 2 WAN are supported for RG-EG105G V2/RG-EG105G-P;

Full Gigabit port : Meet the needs of 200M xDSL/fiber access, high-speed wired connectivity;

AC mode : Manage Reyee APs, saving cost;

Smart flow control : Intelligently adjusted the each user bandwidth according to the access bandwidth and the number of users to ensure that each user can enjoy better network experience;

IPSec VPN : EG Provide VPN services for headquarters and branches, up to 8 branches;

Enterprise Security features : IP/MAC/MAC-Filtering. Independent VLAN for guest , isolated from the internal office network

Technical Specs

Model	RG-EG105G V2
Basic specifications
Fixed ports	5 10/100/1000M Base-T ports, supporting up to 2 WAN ports (Default: 1 WAN port, 4 LAN ports LAN3 can be switched to WAN1 port)
RAM	128MB
Flash	16MB
Maximum number of clients	Up to 100 concurrent clients
Recommended bandwidth	600M asymmetric bandwidth (flow control disabled) 500M asymmetric bandwidth (flow control enabled)
Local power supply	Support 220V AC local power supply
Power consumption	<6W
Basic network
Network access	PPPoE dial-up DHCP client Static IP Automatic identification of access methods Automatic avoidance of WAN port address conflicts MAC cloning Acquiring account from existing routers
Routing	Static routing Policy-based routing Carrier address routing Active/standby mode Load balancing based on source address Flow-based load balancing Port-based weighted load balancing of data streams
Security	ACL IP-MAC binding MAC address filtering Dynamic ARP Static ARP binding NAT NAPT Port mapping
Other protocols	DHCP Server DHCP Client DHCP Option43/138 DNS Client DNS Server DNS Proxy TFTP NTP DDNS
Gateway
Application recognition	Built-in self-developed application signature database to identify applications Support free upgrades
Flow control	Support custom flow control policies IP-based automatic bandwidth assignment
Traffic audit	Real-time traffic audit IP traffic visualization
Behavior management	Time-based and IP policy-based access control Website filtering
VPN	IPsec VPN (8 tunnels) server and client, L2TP, PPTP
Authentication	Marketing authentication : WiFiDog (SMS authentication and one-click authentication) Local authentication : password authentication, QR code authentication, voucher authentication
Wireless management
Management capacity	In AC mode, the maximum management capacity is 300 In gateway mode, the maximum management capacity is 32
AP management	Support multi-SSID configuration SSID hiding Channel setting Power setting AP wired port setting AP online upgrade STA quantity setting STA blacklist and whitelist
Roaming	Support local forwarding roaming Layer 2 roaming Layer 3 roaming between APs Viewing of STA roaming track
Switch management
Management capacity	Maximum manageable cloud managed switches : 128
Port management	Loop protection Port mirroring Port isolation Port configuration PoE configuration Port limit Storm control Static MAC MAC search
Status display	Port statistics monitoring information Cable detection VLAN configuration MAC list
Upgrademanagement	Per-device upgrade Batch upgrade
Value added features
Featured solutions	Single-cable IPTV solution Port service VLAN and network segment isolation solution Smart fault diagnosis solution Intranet penetration solution Auto-networking solution
Management	Eweb and Ruijie Cloud
Physical
Dimensions	206.5×108.5×28 (mm)
Weight	0.84kg
Temperature	Operating temperature : 0ºC ~ 40ºC Storage temperature : -10ºC ~ 70ºC
Humidity	Operating humidity : 10% ~ 90% (non-condensing) Storage humidity : 5% ~ 95% (non-condensing)
