Tplink TL-PA4020P Dubai



Tplink TL-PA4020P Dubai

With advanced HomePlug AV technology, the Tplink TL-PA4020P Dubai can provide users with stable high-speed data transmission rates of up to 500Mbps over a household electric circuit for up to 984′ (300 m).

Description

Tplink TL-PA4020P Powerline Adapter Dubai

Each adapter included in the Tplink TL-PA4020P Dubai HomePlug-AV500 2-Port Powerline Adapter Starter Kit from TP-Link features two Ethernet ports and one power socket. The dual Ethernet ports allow you to connect two Ethernet compatible devices directly to your network. Once connected you can take advantage of data transfer rates of up to 500 Mbps at wire distances of up to 984′ (300 m). You will also find an integrated power socket on each adapter keeping your electrical outlet free. Setup is simple, as all you have to do is plug in the Internet connected adapter to an outlet and plug in the other adapter to an outlet where you need an Internet connection. The integrated pairing button does the rest creating a high speed, encrypted network connection.

Features

Increased Data Transfer Rates
With advanced HomePlug AV technology, the Tplink TL-PA4020P Dubai can provide users with stable high-speed data transmission rates of up to 500Mbps over a household electric circuit for up to 984′ (300 m).
Extra Power Socket for Additional Devices
With its integrated power socket, the Tplink TL-PA4020P Dubai provides convenience for your home network. The integrated power socket allows an additional device or power bar to be connected to the adapter as though it were a normal wall socket.
Pair Button for Easy Network Security
You can set up a powerline network within minutes with TP-LINK’s powerline adapters, just plug in and play. Also, the adapters’ “Pair” buttons can be utilized for securing or managing multiple powerline adapters in your home powerline network.
1. Plug one Internet connected adapter into a nearby power outlet.
2. Connect additional adapters to PCs/laptops/Internet TVs or other networked devices via an Ethernet cable or Wi-Fi and you’re done.
Mains Filter for Better Performance
With its Integrated Mains Filter, the TL-PA4020P TKIT can optimize powerline communication performance by suppressing noise interference generated by surrounding electronic equipment that can affect network performance. That means that users won’t experience a sudden speed drop when a larger power-consuming device is plugged into the power socket.
Reduced Power Consumption
The Tplink TL-PA4020P Dubai features an environment-conscious Power-Saving Mode to automatically switch from its regular “Working Mode” to “Power-Saving Mode” to reduce energy consumption by up to 85%.

Technical Specs

HARDWARE FEATURES
Plug Type EU, UK, FR, US
Standards and Protocols HomePlug AV, IEEE802.3, IEEE802.3u
Interface 2* 10/100Mbps Ethernet Ports, Power Socket
Button Pair Button
Power Consumption
  • Maximum : 5.82W (220V/50Hz)
  • Typical : 5.20W (220V/50Hz)
  • Standby : 0.92W (220V/50Hz)
LED Power, Powerline, Ethernet
Dimensions ( W x D x H ) 3.7 x 2.3 x 1.7 in. (95 x 58 x 42 mm)
Range 300 meters over a single circuit
SOFTWARE FEATURES
Modulation Technology OFDM
Encryption 128-bit AES Encryption
OTHERS
Certification CE, FCC, RoHS
Package Contents
  • Powerline Ethernet Adapter *2
  • Ethernet cable (RJ45) *2
  • Resource CD
  • Quick Installation Guide
System Requirements Windows 8/7/Vista/XP/2000, Mac OS, Linux*
Environment
  • Operating Temperature : 0°C~40°C (32°F~104°F)
  • Storage Temperature : -40°C~70°C (-40°F~158°F)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing
